1.产 品 资 料 介 绍：

1. 提供 5 个可用插槽，左侧为专用电源插槽（仅适配电源模块），Slot 1 专用于 CPU 或 FIP 远程 I/O 扫描模块，Slot 2 及以上支持 I/O 或选件模块。
2. 右侧配备 25 针 D 型母扩展连接器，用于级联更多扩展 / 远程底座，实现系统容量线性扩展。
3. 内置 5VDC 供电，功耗 170mA，能效优于传统型号，单槽最大电流容量 3.4A，满足模块高负载需求。
4. 单底座最大级联距离 15 米（50 英尺），可通过多底座级联构建更大规模 I/O 系统。
5. 每个远程底座内置机架编号 DIP 拨码开关，便于系统识别多底座拓扑，简化组态。
6. 采用标准 DIN 导轨安装，结构紧凑，尺寸约 265×130×142mm（10.43×5.12×5.59 英寸），重量约 1.12kg。
7. 工作温度 0°C 至 60°C，电压稳定性 ±5%，适配工业现场环境，具备 IP20 防护等级。
8. 插槽尺寸差异化设计，防止错插，保障模块安装安全与系统稳定性。
9. 兼容 CPU331、340、341、350 及以上型号，不同 CPU 支持的扩展底座数量不同（如 CPU331/340/341 最多 4 个，CPU350 及以上最多 7 个）。
10. 支持 CE、UL、RoHS 认证，符合国际工业标准，适配严苛环境应用。
11. 内部总线与信号电路优化，提升数据传输效率，减少 CPU 资源占用。
12. 需与 CPU 底板通过专用扩展电缆连接，安装接线规范，维护便捷。
13. 可搭配 IC693PWR 系列电源模块，为底座及所有插槽模块提供稳定供电。
14. 具备完善的抗干扰设计，适应电磁干扰复杂的工业现场，保障系统可靠运行。
15. 可用于制造业、石油化工、水处理、机器人控制、数据采集系统等场景，扩展系统 I/O 能力。

结尾

IC693CHS398插槽扩展底座 产品英文

IC693CHS398 is a 5-slot expansion base for GE Fanuc Series 90-30 PLC, used to expand system I/O capacity. It needs to be used in series with the CPU motherboard and cannot run independently. It is suitable for industrial automation scenarios that require adding I/O points or expanding option modules.

Provide 5 available slots, with a dedicated power slot on the left (only compatible with power modules). Slot 1 is dedicated to CPU or FIP remote I/O scanning modules, while Slot 2 and above support I/O or option modules.

The right side is equipped with a 25 pin D-type female expansion connector for cascading more expansion/remote bases, achieving linear expansion of system capacity.

Built in 5VDC power supply, power consumption of 170mA, energy efficiency better than traditional models, single slot maximum current capacity of 3.4A, meeting the high load requirements of the module.

The maximum cascading distance of a single base is 15 meters (50 feet), and larger scale I/O systems can be constructed through cascading multiple bases.

Each remote base is equipped with a DIP dip switch for rack identification, which facilitates system recognition of multiple base topologies and simplifies configuration.

Installed using standard DIN rails, the structure is compact, with dimensions of approximately 265 × 130 × 142mm (10.43 × 5.12 × 5.59 inches) and a weight of approximately 1.12kg.

The working temperature ranges from 0 ° C to 60 ° C, with a voltage stability of ± 5%, suitable for industrial site environments, and has an IP20 protection level.

Differentiated slot size design to prevent incorrect insertion and ensure safe module installation and system stability.

Compatible with CPU 331, 340, 341, 350 and above models, the number of expansion bases supported by different CPUs varies (e.g. up to 4 for CPU 331/340/341 and up to 7 for CPU 350 and above).

Supports CE, UL, RoHS certification, complies with international industrial standards, and is suitable for harsh environmental applications.

Internal bus and signal circuit optimization to improve data transmission efficiency and reduce CPU resource usage.

It needs to be connected to the CPU motherboard through a dedicated expansion cable, with standardized installation and wiring, and easy maintenance.

Can be paired with IC693PWR series power modules to provide stable power supply for the base and all slot modules.

Equipped with comprehensive anti-interference design, suitable for complex industrial sites with electromagnetic interference, ensuring reliable operation of the system.

Can be used in manufacturing, petrochemicals, water treatment, robot control, data acquisition systems, and other scenarios to expand system I/O capabilities.

ending

IC693CHS398, with its core features of flexible expansion, easy installation, and stable reliability, has become the standard choice for Series 90-30 PLC systems to expand I/O capacity, helping to build modular and scalable industrial automation control architectures.

IC693CHS398插槽扩展底座  产品展示
