GIDINGS&LEWIS 810-22360-01控制面板

1.产 品 资 料 介 绍：

GIDINGS&LEWIS 810 - 22360 - 01 控制面板介绍

一、功能定位

二、操作界面设计

1. 显示区域：配备了高清晰度的背光 LCD 显示屏，能够清晰呈现丰富的信息。开机后，RUN LED 指示灯亮起，此时 LCD 画面会显示设备的初始状态，如设备是否就绪、各轴的当前位置、系统的运行模式等基础信息。在设备运行过程中，LCD 显示屏会动态更新设备的实时运行数据，如电机转速、温度、压力等参数，方便操作人员随时掌握设备工况。并且，当设备出现故障时，显示屏会以醒目的方式弹出故障代码及简要的故障描述，帮助技术人员快速定位问题。
2. 按键布局：控制面板上的按键布局经过精心设计，具有良好的人机工程学特性。按键功能明确，包括启动、停止、急停、复位等基本控制按键，以及用于参数调整的数字按键、方向按键和功能切换按键等。按键触感舒适，反馈灵敏，操作人员在操作过程中能够轻松准确地按下所需按键，减少误操作的概率。同时，为了防止在紧急情况下误操作，急停按键通常采用醒目的颜色和较大的尺寸设计，并且具有明显的凸起，方便操作人员在紧急时刻能够迅速按下。

英文资料：

GIDINGS&LEWIS 810-22360-01 Control Panel Introduction

In industrial automation control systems, the control panel serves as a key hub for human device interaction, undertaking important responsibilities such as command issuance, status monitoring, and parameter adjustment. The GIDINGS&LEWIS 810-22360-01 control panel plays a central role in many industrial scenarios with its outstanding performance and user-friendly design.

1、 Functional positioning

This control panel is the core interactive component of industrial automation systems, building a bridge for communication between operators and complex industrial equipment. On the one hand, operators can send various control commands to the system through this panel, whether it is starting, stopping equipment, or adjusting equipment operating parameters, all of which can be accurately conveyed. For example, in the process of CNC machine tool machining, technicians can quickly set key parameters such as machining speed and feed rate through the panel; In automated production lines, real-time control of material conveying speed and production pace can be achieved through it. On the other hand, it provides real-time feedback on the operating status of the equipment, presenting the equipment's operational data, fault information, and other visual information to operators, in order to promptly identify problems and take corresponding measures, ensuring the stable and efficient operation of the equipment.

2、 Operation interface design

Display area: Equipped with a high-definition backlit LCD display screen, it can clearly present rich information. After booting up, the RUN LED indicator light will turn on, and the LCD screen will display the initial status of the device, such as whether the device is ready, the current position of each axis, the system's operating mode, and other basic information. During the operation of the equipment, the LCD display screen will dynamically ｕｐｄａｔｅ the real-time operating data of the equipment, such as motor speed, temperature, pressure and other parameters, making it convenient for operators to grasp the equipment working conditions at any time. And when the device malfunctions, the display screen will prominently display the fault code and brief fault description, helping technicians quickly locate the problem.

Button layout: The button layout on the control panel has been carefully designed with excellent ergonomic features. The button functions are clear, including basic control buttons such as start, stop, emergency stop, reset, as well as numerical buttons, directional buttons, and function switching buttons for parameter adjustment. The button touch is comfortable, the feedback is sensitive, and the operator can easily and accurately press the required button during the operation process, reducing the probability of misoperation. At the same time, in order to prevent accidental operation in emergency situations, emergency stop buttons are usually designed with eye-catching colors and larger sizes, and have obvious protrusions, making it convenient for operators to quickly press them in emergency situations.

 2.产      品      展      示
