2223B001300继电器卡

2223B001300继电器卡

1.产 品 资 料 介 绍：

2223B001300继电器卡产品特点

1. 支持多通道继电器输出，触点配置丰富，可同时实现多路负载独立控制，适配复杂工业控制场景。

2. 采用高品质继电器元件，触点接触电阻低、通断性能稳定，机械寿命≥1000万次，电气寿命长，可靠性高。

3. 具备输入与输出电气隔离设计，隔离电压高达4000VAC，有效阻断电路间干扰，保障系统运行安全。

4. 支持宽电压供电输入（DC 9-36V），抗电压波动能力强，适配多种工业电源系统，应用灵活性高。

5. 兼容标准Modbus-RTU通信协议，通过RS485接口实现上位机远程控制与状态监控，运维便捷高效。

6. 配备16路继电器状态LED指示灯，直观反馈每路触点通断状态，便于现场快速排查故障。

7. 支持热插拔功能，系统运行中可安全插拔模块，不影响整体系统工作，提升维护效率。

8. 集成过流、浪涌保护机制，电接口具备1.5A过流、600W浪涌防护能力，有效保护模块与后端设备。

9. 采用波浪纹铝制加强机壳，IP30防护等级，抗粉尘、抗振动，适应恶劣工业环境。

10. 支持继电器驱动反相逻辑选择，可通过跳线设置正常通电或正常断电模式，适配不同控制需求。

11. 符合欧盟EMC电磁兼容标准，抗电磁干扰能力优异，保障复杂电磁环境下信号传输与控制的稳定性。

12. 采用标准35mm工业导轨安装方式，安装拆卸便捷，节省控制柜内部空间，便于系统集成部署。

13. 触点额定电压250VAC、额定电流5A，分断能力强，可安全驱动各类工业负载，适用范围广。

14. 支持干接点信号输入，适配无源触点与DC5-30V PNP型信号，兼容性强，可对接多种传感器与控制器。

15. 广泛应用于工厂自动化、流水线控制、电力系统保护等领域，可实现设备联动、故障告警等多种控制功能。

2223B001300继电器卡 英文资料：

2223B001300 Relay Card Product Features

1. Supports multi-channel relay output, rich contact configuration, and can achieve independent control of multiple loads simultaneously, suitable for complex industrial control scenarios.

2. High quality relay components are used, with low contact resistance and stable on-off performance. The mechanical life is ≥ 10 million times, the electrical life is long, and the reliability is high.

3. Equipped with input and output electrical isolation design, the isolation voltage can reach up to 4000VAC, effectively blocking interference between circuits and ensuring the safe operation of the system.

4. Supports wide voltage power input (DC 9-36V), strong resistance to voltage fluctuations, adaptable to various industrial power systems, and high application flexibility.

5. Compatible with the standard Modbus RTU communication protocol, remote control and status monitoring of the upper computer are achieved through RS485 interface, making operation and maintenance convenient and efficient.

6. Equipped with 16 relay status LED indicator lights, providing intuitive feedback on the on/off status of each contact, facilitating quick troubleshooting on site.

7. Support hot swapping function, modules can be safely plugged in and out during system operation without affecting the overall system operation, improving maintenance efficiency.

8. Integrated overcurrent and surge protection mechanisms, with electrical interfaces capable of 1.5A overcurrent and 600W surge protection, effectively protecting modules and backend devices.

9. The chassis is reinforced with wavy aluminum, with an IP30 protection level, resistant to dust and vibration, and suitable for harsh industrial environments.

10. Supports relay driven reverse logic selection, and can be set to normal power on or off mode through jumper wires to adapt to different control requirements.

11. Compliant with the EU EMC electromagnetic compatibility standards, with excellent resistance to electromagnetic interference, ensuring the stability of signal transmission and control in complex electromagnetic environments.

12. Adopting standard 35mm industrial guide rail installation method, easy installation and disassembly, saving internal space of the control cabinet, and facilitating system integration and deployment.

13. The rated voltage of the contact is 250VAC and the rated current is 5A. It has strong breaking ability and can safely drive various industrial loads, with a wide range of applications.

14. Supports dry contact signal input, compatible with passive contacts and DC5-30V PNP signals, strong compatibility, and can be connected to various sensors and controllers.

Widely used in fields such as factory automation, assembly line control, and power system protection, it can achieve various control functions such as equipment linkage and fault alarm.
