Delta Tau 0190-26873数据系统模块

Delta Tau 0190-26873数据系统模块

1.产 品 资 料 介 绍：

1. 品牌型号：美国 Delta Tau（现欧姆龙自动化），物料号0190-26873，对应核心型号UMAC-CPCI Turbo CPU（603625-102A）。
2. 核心定位：UMAC 系列运动控制系统的Turbo 级 CPU 核心模块，负责多轴实时运动控制与数据处理。
3. 系统架构：基于 CPCI 总线的 3U 模块化设计，适配 UMAC 机架，支持多轴协同与扩展。
4. 处理器配置：搭载高性能Turbo PMAC DSP，主频 80MHz，支持高速伺服环路运算。
5. 内存规格：内置256k×24 SRAM与1M×8 Flash，用于程序运行、数据缓存与固件存储。
6. 通信接口：标配100Mbps 以太网、RS-232 串口，支持 EtherCAT、MACRO 等工业总线扩展。
7. 轴控能力：单模块支持多轴伺服 / 步进控制，可扩展至 32 轴同步，适配高精度运动场景。
8. 伺服性能：内置PID + 前馈 + 陷波滤波算法，伺服采样频率≥20kHz，动态响应 < 1ms。
9. 编码器接口：每轴支持 3 通道差分 ABZ 编码器，兼容增量式、光栅型，适配单端 / 差分信号。
10. 模拟输出：每轴提供 12 位 ±10V 模拟量输出，用于驱动伺服放大器。
11. I/O 资源：集成 32 路通用数字 I/O，支持光电隔离，适配工业传感器与执行器。
12. 供电规格：5V DC 为主供电，±12V DC 辅助供电，适配工业控制系统标准电源。
13. 硬件防护：工业级 PCB 设计，金属屏蔽外壳，抗电磁干扰，适应严苛工业环境。
14. 应用场景：半导体设备、光刻机、精密机床、机器人、自动化生产线等高精度运动控制领域。
15. 兼容替换：可直接替换同系列 UMAC-CPCI Turbo CPU 模块（如 603625-104），系统无缝兼容。

Delta Tau 0190-26873数据系统模块  英文资料：

Brand and model: Delta Tau (now Omron Automation) from the United States, material number 0190-26873, corresponding to the core model UMAC-CPCI Turbo CPU (603625-102A).

Core positioning: Turbo level CPU core module of UMAC series motion control system, responsible for multi axis real-time motion control and data processing.

System architecture: 3U modular design based on CPCI bus, compatible with UMAC rack, supporting multi axis collaboration and expansion.

Processor configuration: Equipped with high-performance Turbo PMAC DSP, with a main frequency of 80MHz, supporting high-speed servo loop operation.

Memory specifications: Built in 256k × 24 SRAM and 1M × 8 Flash, used for program execution, data caching, and firmware storage.

Communication interface: Standard configuration includes 100Mbps Ethernet and RS-232 serial port, supporting industrial bus extensions such as EtherCAT and MACRO.

Axis control capability: Single module supports multi axis servo/stepper control, expandable to 32 axis synchronization, suitable for high-precision motion scenes.

Servo performance: Built in PID+feedforward+notch filtering algorithm, servo sampling frequency ≥ 20kHz, dynamic response<1ms.

Encoder interface: Each axis supports 3-channel differential ABZ encoder, compatible with incremental and grating types, and suitable for single ended/differential signals.

Analog output: Each axis provides a 12 bit ± 10V analog output for driving servo amplifiers.

I/O resources: Integrate 32 universal digital I/O channels, support optoelectronic isolation, and adapt to industrial sensors and actuators.

Power supply specifications: 5V DC main power supply, ± 12V DC auxiliary power supply, compatible with industrial control system standard power supply.

Hardware protection: Industrial grade PCB design, metal shielding shell, anti electromagnetic interference, suitable for harsh industrial environments.

Application scenarios: High precision motion control fields such as semiconductor equipment, lithography machines, precision machine tools, robots, and automated production lines.

Compatible Replacement: It can directly ｒｅｐｌａｃｅ UMAC-CPCI Turbo CPU modules of the same series (such as 603625-104), and the system is seamlessly compatible.

In summary, Delta Tau 0190-26873 (UMAC-CPCI Turbo CPU) is the core computing unit of UMAC motion control system, with Turbo level DSP computing power, multi axis high-precision synchronization, rich communication interfaces, and industrial grade reliability as its core advantages. It is a key module for high-end precision motion control.
