1.产 品 资 料 介 绍：
Fujitsu PA03585-D310 单板计算机产品特点
开头
- 定制嵌入式处理器，满足半导体设备工艺运算、数据采集算力需求
- 板载多通道 DDR 内存插槽，读写稳定，批量工艺数据缓存不卡顿
- 双路 CF 卡双存储架构，一卡系统一卡存生产日志，数据双重备份
- 搭载三路独立千兆网口，分区传输设备控制、画面、采集数据
- 集成 DVI 显示输出接口，直连机台操作显示屏，画面输出无延迟
- 预留多路 DIO 数字输入输出通道，对接传感器、电磁阀、限位组件
- 前置多组 USB 拓展口，可外接键鼠、U 盘、检测外设，运维便捷
- 一体式金属屏蔽散热罩，隔绝车间电磁干扰同时均衡散热
- 标准机架插卡结构，插拔式安装，更换检修无需拆解整机腔体
- 内置硬件看门狗电路，程序卡死自动重启，避免产线停机报错
- 宽压稳压电源回路，车间电压波动工况持续稳定工作
- 板载整机状态监测芯片，实时读取板卡温度、电压运行参数
- 多层加厚 PCB 基材，抗设备震动冲击，线路不易断线分层
- 兼容工业主流 Windows 嵌入式系统，适配各类半导体工艺程序
- 无铅原厂工艺，符合 RoHS 标准，满足洁净半导体产线合规要求
结尾
Fujitsu PA03585-D310单板计算机 产品英文
Fujitsu PA03585-D310 Single Board Computer Product Features
beginning
Fujitsu PA03585-D310 is a plug-in single board computer specifically designed for Fujitsu's original semiconductor equipment. It is equipped with a TEL wafer machine main control system, with stable computing and complete interfaces, and is suitable for 24/7 uninterrupted operation on production lines.
Customized embedded processors to meet the computing power requirements for semiconductor device process operations and data acquisition
Onboard multi-channel DDR memory slot, stable read and write, batch process data caching without buffering
Dual channel CF card dual storage architecture, one card system and one card storage for production logs, dual backup of data
Equipped with three independent gigabit network ports, partition transmission equipment control, screen, and data collection
Integrated DVI display output interface, directly connected to the machine operation display screen, with no delay in image output
Reserve multiple DIO digital input and output channels for docking sensors, solenoid valves, and limit components
Front mounted multiple USB expansion ports, capable of external keyboard, mouse, USB flash drive, and detection peripherals for convenient operation and maintenance
Integrated metal shielding heat dissipation cover, isolates electromagnetic interference in the workshop while balancing heat dissipation
Standard rack card insertion structure, plug-in installation, no need to disassemble the entire machine cavity for replacement and maintenance
Built in hardware watchdog circuit, automatically restarts when program freezes, avoiding production line shutdown and error reporting
Wide voltage stabilized power supply circuit, continuous and stable operation under workshop voltage fluctuation conditions
Onboard whole machine status monitoring chip, real-time reading of board temperature and voltage operating parameters
Multi layer thickened PCB substrate, resistant to equipment vibration and impact, and the circuit is not easily broken or layered
Compatible with mainstream industrial Windows embedded systems and compatible with various semiconductor process programs
Lead free original factory process, compliant with RoHS standards, meets the compliance requirements of clean semiconductor production lines
ending
Fujitsu PA03585-D310 single board computer combines computing power, expansion, and durability, making it the core computing control board for TEL semiconductor equipment.
Fujitsu PA03585-D310单板计算机 产品展示
