AMAT Applied Materials 0100-00016智能接口组件板

AMAT Applied Materials 0100-00016智能接口组件板

1.产 品 资 料 介 绍：

AMAT Applied Materials 0100-00016智能接口组件板 英文资料：

1、 Multi type interface integration: achieving seamless interconnection of semiconductor device modules

As the "interface hub" of semiconductor devices, the 0100-00016 intelligent interface component board focuses on full scene interface adaptation, breaking down communication barriers between different modules and providing a unified data exchange channel for various functional units of the device

Rich interface type coverage

Multiple types of interfaces commonly used in integrated semiconductor equipment to meet the connection requirements of different modules:

Industrial communication interface: 2 Gigabit Ethernet ports (supporting Profinet and EtherNet/IP protocols), 4 RS485 serial ports (communication rate adjustable from 0-1Mbps), and 1 CAN bus interface (supporting CANopen protocol), which can interface with device main controllers, sensor clusters, and actuators (such as servo motor drivers) to achieve real-time transmission of control instructions and status data;

Signal conversion interface: 8-channel analog input/output interface (supporting 4-20mA current signal, 0-10V voltage signal), 16 channel digital input/output interface (compatible with TTL/CMOS level), can convert analog signals collected by sensors (such as temperature and pressure) into digital signals and transmit them to the controller. At the same time, the controller's digital instructions are converted into analog signals to drive the actuator, without the need for additional signal conversion modules;

Special functional interfaces: 1 USB 3.0 interface (for local data export and parameter configuration), 1 fiber optic interface (supporting long-distance high-speed transmission, transmission distance ≤ 10km), suitable for factory long-distance equipment layout and local operation and maintenance needs, balancing data transmission efficiency and operational convenience.

Independent control and isolation of interfaces

Each interface channel adopts independent circuit design, with an isolation degree of ≥ 2500V AC between channels to avoid cross interference of different types of signals - for example, analog signals and digital signals are wired in different areas, and analog channels are equipped with dedicated shielding layers (shielding attenuation ≥ 40dB) to ensure that mV level weak sensor signals are not affected by digital signal interference during transmission, and signal acquisition error is ≤± 0.2% F.S; At the same time, each interface is equipped with independent overcurrent protection (overcurrent threshold 1.5 times the rated current) to prevent a single interface failure from affecting the normal operation of other channels and improve overall operational reliability.

Protocol automatic adaptation capability

Built in protocol recognition and conversion chip, supporting automatic identification of communication protocols for access devices (such as automatic matching of Profinet or EtherNet/IP protocols), without the need for manual configuration of protocol parameters; For non-standard protocol devices (such as some third-party sensors), the protocol frame format can be customized through onboard configuration software to achieve compatible communication with the device's main system. The protocol adaptation cycle is shortened from the traditional 24 hours to within 1 hour, greatly improving device integration efficiency.

AMAT Applied Materials 0100-00016智能接口组件板 产品展示
