AMAT Applied Materials 333-52-851564分析板

AMAT Applied Materials 333-52-851564分析板

1.产 品 资 料 介 绍：

AMAT Applied Materials 333-52-851564分析板 英文资料：

1、 Core detection and analysis performance characteristics

Multi dimensional signal precise acquisition capability

Specially designed for semiconductor process testing, it integrates multiple high-precision sensing interfaces (presumably supporting 8-16 analog signal inputs), which can synchronously collect key process parameters such as gas concentration, temperature, pressure, and flow rate. Equipped with a 12 bit analog-to-digital converter (ADC) with a conversion accuracy of ± 0.1% FS, coupled with a low-noise amplification circuit, it can capture small signal fluctuations (such as ppm level gas concentration changes) and provide raw data support for process monitoring.

High speed data processing and intelligent analysis functions

Equipped with an industrial grade RISC-V architecture microcontroller (referring to the AiP32RV1564 core characteristics), the operating frequency can reach 144MHz, with a computing efficiency of 1.84 DMIPS/MHz, and can perform real-time algorithms such as signal filtering, data calibration, and trend analysis. Built in 64KB Flash and 20KB SRAM memory, supports local caching of detection data for more than 15 days (recorded at 1-minute intervals), and automatically generates timestamp logs to meet process traceability requirements.

Multi parameter linkage analysis and alarm response

Support dual independent concentration alarm settings, customizable alarm threshold, delay time, and switch logic. When the detection parameters exceed the standard range (such as harmful gas concentration exceeding the standard), an alarm signal can be triggered within 10ms. Built in fault diagnosis algorithm can automatically identify sensor abnormalities, signal disconnections, and other issues, and generate corresponding error codes to help quickly locate the root cause of the fault.

2、 System collaboration and monitoring features

Full link data communication and integration capability

Equipped with rich standardized communication interfaces, including 2 SPI, 2 I2C, 3 UART, and 1 CAN bus, it can seamlessly interface with 0190-24007 single board computers, MES systems, and sensor networks. Supports Modbus communication protocol, can upload real-time detection data, device status, and alarm information, achieve closed-loop linkage between detection data and production control system, and assist in dynamic adjustment of process parameters.

Visual state monitoring and remote management

Compatible with the AMAT Command Center universal software platform, it can automatically identify the device model after connecting to the upper computer, display a customized monitoring interface, and intuitively present 12 key parameters such as detection values, sensor life, and board temperature. Support remote calibration and firmware upgrade, and operation and maintenance personnel can adjust the detection range (such as switching between 4-20mA and 1-5V signals) through the backend system without on-site operation.

Anti interference and signal isolation design

Adopting optoelectronic isolation technology (isolation voltage ≥ 2500V DC), the acquisition circuit and processing circuit are physically isolated, effectively resisting electromagnetic interference generated by RF equipment and motors. The onboard EMC filtering circuit complies with the EN 55022 Class B electromagnetic compatibility standard, avoiding measurement deviation caused by stray interference in the detection signal and ensuring data reliability.
