TRICONEX 8312电源模块
1.产 品 资 料 介 绍：
- 双隔离冗余供电：采用双隔离电源设计，两路电源可自动切换，一路故障不影响系统供电，搭配电源滤波功能，抵御电压波动，保障动力持续稳定。
- 宽电压输入适配：支持 220-380V 宽范围交流输入，不用额外配置变压器，能适配电厂、化工厂等不同工业电网规格，降低电源适配成本。
- 三重冗余保安全：沿用 TRICONEX 标志性 TMR 架构，三个独立回路同步供电并互校状态，单个回路故障自动屏蔽，符合 IEC 61508 安全标准，高危场景供电无中断。
- 全面保护防损坏：自带过载、过温、短路保护，输出电流可适配 550A 至 3500A 多种规格，负载异常时快速切断电源，避免模块及后端设备烧毁。
- 低耗节能运行：整机功耗≤20W，相比普通电源模块能耗降低 30%，且支持轻载自适应降频，长期运行能显著减少工业用电成本，适配本安电源应用场景。
- 支持在线维护：可带电热插拔，系统运行中能更换模块或检修，不用停线操作，特别适合石油、化工等连续生产场景，提升设备利用率。
- 智能状态诊断：通过 LED 指示灯实时显示供电状态、故障信息，配合系统日志记录电源异常，能快速定位过载、过压等问题，减少排查时间。
- 工业环境适配强：工作温度覆盖 - 20℃至 50℃，电路板带防潮处理，能适应 10%~90% RH 高湿度环境，在多粉尘的钢铁厂、电厂也能稳定运行。
- 精准对接安全系统：无缝适配 TRICONEX TMR 安全控制系统，可直接为 I/O 模块、通信模块供电，插装后无需调整参数，快速搭建动力链路。
- 高耐用长寿命：外壳采用防腐蚀材质，关键元器件选工业级芯片，支持无损传输，平均无故障工作时间超 10 万小时，适合长期连续运行场景。
TRICONEX 8312电源模块 英文资料：
Dual isolation redundant power supply: adopting a dual isolation power supply design, the two power supplies can automatically switch, and the failure of one power supply does not affect the system power supply. Combined with power filtering function, it can resist voltage fluctuations and ensure continuous and stable power supply.
Wide voltage input adaptation: Supports 220-380V wide range AC input without the need for additional transformers, and can adapt to different industrial power grid specifications such as power plants and chemical plants, reducing power supply adaptation costs.
Triple redundancy ensures safety: using the iconic TMR architecture of TRICONEX, three independent circuits are synchronously powered and mutually calibrated, and a single circuit fault is automatically shielded, in compliance with IEC 61508 safety standards, ensuring uninterrupted power supply in high-risk scenarios.
Comprehensive protection against damage: Equipped with overload, over temperature, and short circuit protection, the output current can adapt to various specifications from 550A to 3500A. When the load is abnormal, the power can be quickly cut off to avoid module and backend equipment burning out.
Low consumption and energy-saving operation: The overall power consumption of the machine is ≤ 20W, which is 30% lower than that of ordinary power modules. It also supports light load adaptive frequency reduction, and long-term operation can significantly reduce industrial electricity costs, making it suitable for intrinsically safe power supply application scenarios.
Support online maintenance: It can be equipped with electric hot plugging, and modules can be replaced or repaired during system operation without stopping the line. It is particularly suitable for continuous production scenarios such as petroleum and chemical industries, improving equipment utilization.
Intelligent status diagnosis: Real time display of power supply status and fault information through LED indicator lights, combined with system logging to record power abnormalities, can quickly locate overload, overvoltage and other issues, reducing troubleshooting time.
Strong adaptability to industrial environment: The working temperature covers -20 ℃ to 50 ℃, and the circuit board is treated with moisture-proof measures, which can adapt to high humidity environments of 10% to 90% RH. It can also operate stably in dusty steel plants and power plants.
Precise integration with safety system: seamlessly adapted to the TRICONEX TMR safety control system, it can directly supply power to I/O modules and communication modules, without the need to adjust parameters after insertion, and quickly establish power links.
High durability and long lifespan: The casing is made of corrosion-resistant materials, and key components are selected from industrial grade chips. It supports non-destructive transmission and has an average fault free working time of over 100000 hours, making it suitable for long-term continuous operation scenarios.
TRICONEX 8312电源模块 产品展示
