IC697MDL240独立逻辑输入模块

1.产 品 资 料 介 绍：

IC697MDL240 独立逻辑输入模块

一、核心规格与硬件特性

1. 通道与电压：16 路独立隔离输入，额定 120VAC、60Hz，单通道可接不同 AC 相位，系统灵活性高。
2. 输入特性：容性（RC）输入电路，符合 IEC 61131‑2 Type 2 标准；导通电流约 10mA / 通道，关断漏电流 ≤ 4mA，兼容 2‑/3‑线接近开关、限位开关、按钮等。
3. 电气隔离：通道间 1500VAC 光电隔离，彻底阻断地环流与 EMI/RFI 干扰，保障信号纯净。
4. 滤波与响应：内置 20ms 固定输入滤波，有效滤除现场高频噪声，提升信号稳定性。
5. 状态指示：顶部 16 个独立 LED，实时显示每通道 ON/OFF 状态，现场排查直观高效。
6. 安装与供电：单槽位 90‑70 机架安装，直接接入 VME 背板；从背板 5V 总线取电，电流约 0.25A，功耗低。
7. 机械键控：防误插设计，确保同类型模块可安全替换。

二、配置与兼容性

1. 软件配置：全参数通过编程软件（如 Logicmaster、VersaPro）完成，无跳线 / 拨码开关，支持以太网 TCP/IP 或 SNP 端口配置。
2. 系统兼容：完美适配 90‑70 系列 CPU（如 IC697CSE784、IC697CSE925），I/O 地址可自由分配。
3. 环境适应：工业级宽温 ‑20℃～+70℃，防护等级 IP20，适应车间粉尘、振动等恶劣工况。

三、典型应用场景

• 机床、输送线、包装设备的交流限位 / 光电信号采集
• 配电柜、电机控制回路的状态监测与安全联锁
• 纺织、印刷、食品加工等 120VAC 供电场景的离散控制
• 多相 AC 电源系统的跨相位信号采集

四、核心优势

• 高隔离 + 强抗扰：1500VAC 隔离 + 20ms 滤波，在复杂电磁环境下仍稳定可靠。
• 多相兼容：单模块支持跨 AC 相位输入，简化系统布线与设计。
• 易维护：LED 状态灯 + 软件配置，安装调试与故障定位效率高。
• 低功耗长寿命：容性电路发热小，适合长期连续运行。

IC697MDL240独立逻辑输入模块 英文资料：

IC697MDL240 independent logic input module

IC697MDL240 is a 16 channel 120VAC isolated digital input module from GE Fanuc 90-70 series, designed specifically for industrial field AC switch signal acquisition. It features strong isolation, anti-interference, and adaptability to multiphase power supplies, and is widely used for equipment status monitoring, safety interlocking, and logic control.

1、 Core specifications and hardware features

Channel and voltage: 16 independent isolated inputs, rated at 120VAC, 60Hz, single channel can be connected to different AC phases, with high system flexibility.

Input characteristics: Capacitive (RC) input circuit, compliant with IEC 61131-2 Type 2 standard; The conduction current is about 10mA/channel, the cut-off leakage current is ≤ 4mA, and it is compatible with 2-/3 line proximity switches, limit switches, buttons, etc.

Electrical isolation: 1500VAC photoelectric isolation between channels completely blocks ground current and EMI/RFI interference, ensuring signal purity.

Filtering and Response: Built in 20ms fixed input filter, effectively filtering out high-frequency noise on site and improving signal stability.

Status indication: The top 16 independent LEDs display the real-time ON/OFF status of each channel, making on-site inspections intuitive and efficient.

Installation and power supply: Single slot 90-70 rack installation, directly connected to VME backplane; Powered from the 5V bus on the backplane, with a current of approximately 0.25A and low power consumption.

Mechanical key control: designed to prevent accidental insertion, ensuring safe replacement of modules of the same type.

2、 Configuration and compatibility

Software configuration: All parameters are completed through programming software (such as Logicmaster, VersaPro), without jumper/dip switch, supporting Ethernet TCP/IP or SNP port configuration.

System compatibility: Perfectly compatible with 90-70 series CPUs (such as IC697CSE784, IC697CSE925), I/O addresses can be freely allocated.

Environmental adaptation: Industrial grade wide temperature range of -20 ℃ to+70 ℃, protection level of IP20, suitable for harsh working conditions such as workshop dust and vibration.

3、 Typical application scenarios

AC limit/photoelectric signal acquisition for machine tools, conveyor lines, and packaging equipment

Status monitoring and safety interlocking of distribution cabinets and motor control circuits

Discrete Control of 120VAC Power Supply Scenarios in Textile, Printing, Food Processing, etc

Cross phase signal acquisition of multiphase AC power supply system

4、 Core advantages

High isolation+strong anti-interference: 1500VAC isolation+20ms filtering, stable and reliable in complex electromagnetic environments.

Multiphase compatibility: Single module supports cross AC phase input, simplifying system wiring and design.

Easy to maintain: LED status light+software configuration, high efficiency in installation, debugging, and fault location.

Low power consumption and long lifespan: Capacitive circuits generate less heat and are suitable for long-term continuous operation.

IC697MDL240独立逻辑输入模块 产品展示

产品视频
