1.产 品 资 料 介 绍：
- 发那科（FANUC）原装绝对式伺服电机编码器，专为精密运动控制设计，核心作用是将机械运动转化为电信号，实现位置、速度的精准监控
- 品牌：日本发那科（FANUC），适配机型：专为 FANUC βiA128 系列伺服电机配套使用
- 产品状态：全新原装与翻新件均有供应，第三方渠道提供现货，部分支持质保服务
- 精度与信号：分辨率达 25 位（约 3300 万脉冲 / 转），支持 90° 反相位 2 位输出波形，3 通道型号含 1 脉冲 / 转输出
- 通信与接口：支持 S7 总线协议、RS-422 协议，17 芯航空插头连接，增量式 / 绝对式双模式输出
- 供电与环境：DC5V±5% 供电（TTL 兼容输出），工作温度 - 25℃至 85℃（部分版本耐 - 40℃~100℃），防护等级 IP67
- 物理与性能：体积紧凑（参考尺寸 Φ58mm×85mm），重量约 0.35kg，抗振动等级 10G（10-2000Hz），信号刷新率高达 500kHz
- 核心功能：断电后无需重新初始化，可直接报告当前位置；抗干扰能力强，线性误差仅 ±0.005%（全量程）
- 应用场景：数控机床（铣削、车削、钻孔）、工业机器人、木工机械、纺织机械、医疗设备、雕刻机等精密设备
- 替代与兼容：兼容 FANUC 0i/30i/31i 系列 CNC 系统，可替代 A860-2005-T301 型号，与同系列 A860-2000-T301 功能互通
A860-2020-T301编码器 英文资料：
1、 Core positioning
FANUC's original absolute servo motor encoder is designed specifically for precision motion control. Its core function is to convert mechanical motion into electrical signals, achieving precise monitoring of position and speed
Brand: FANUC, Suitable for FANUC β iA128 series servo motors
Product status: Both brand new original and refurbished parts are available, third-party channels provide in stock, and some support warranty services
2、 Key parameters
Accuracy and Signal: Resolution up to 25 bits (approximately 33 million pulses per revolution), supporting 90 ° anti phase 2-bit output waveform, 3-channel model with 1 pulse per revolution output
Communication and Interface: Supports S7 bus protocol, RS-422 protocol, 17 core aviation plug connection, incremental/absolute dual-mode output
Power supply and environment: DC5V ± 5% power supply (TTL compatible output), operating temperature -25 ℃ to 85 ℃ (some versions can withstand -40 ℃~100 ℃), protection level IP67
Physics and Performance: Compact in size (reference size Φ 58mm × 85mm), weighing approximately 0.35kg, with a vibration resistance level of 10G (10-2000Hz), and a signal refresh rate of up to 500kHz
3、 Core functions and applications
Core function: After power failure, there is no need to reinitialize, and the current position can be directly reported; Strong anti-interference ability, with a linear error of only ± 0.005% (full range)
Application scenarios: CNC machine tools (milling, turning, drilling), industrial robots, woodworking machinery, textile machinery, medical equipment, carving machines and other precision equipment
Substitution and Compatibility: Compatible with FANUC 0i/30i/31i series CNC systems, can ｒｅｐｌａｃｅ A860-05-T301 models, and is functionally compatible with A860-2000-T301 of the same series
A860-2020-T301编码器 产品展示
产品视频
