65040-PA52-BHK温度控制模块

1.产 品 资 料 介 绍：

65040-PA52-BHK 温度控制模块产品特点

1. 采用工业级高精度测温芯片，兼容热电偶（K/J/T/E 等）与 RTD（Pt100/Pt1000）输入，测量精度可达 ±0.1℃，适配多种工业测温场景。
2. 内置自适应 PID 控制算法，支持加热 / 冷却双向控制，可自动调节参数，有效抑制超调与振荡，实现快速恒温控制。
3. 测量温度范围覆盖 - 200℃~+1800℃，可适配低温冷冻、高温热处理等不同温度区间的工业控制需求。
4. 支持多路温度采集与控制，最多可接入 8 路测温通道，单模块即可满足多区域温度同步监控与独立调节需求。
5. 提供继电器、固态继电器、4-20mA 模拟量等多种输出方式，适配加热器、冷却阀等不同执行机构，负载能力达 AC250V/5A。
6. 集成 RS485 通讯接口，支持 Modbus-RTU 协议，可与 PLC、HMI 及上位机通信，实现远程参数设置与数据采集。
7. 配备高亮 LED 数码显示与按键操作区，实时显示测量值、设定值及运行状态，参数调整直观便捷。
8. 内置多重报警功能，含超温报警、传感器故障报警、输出异常报警等，支持声光报警与报警触点输出，及时预警风险。
9. 具备断电数据保存功能，可存储设定参数与历史温度记录，恢复供电后自动恢复控制状态，避免作业中断。
10. 输入、输出、电源三端电气隔离，抗干扰能力强，可有效抵御工业现场电磁干扰，保障测量与控制稳定性。
11. 支持温度补偿功能，自动修正环境温度与传感器引线电阻带来的测量误差，提升测温精度。
12. 工作温度范围 - 20℃~+60℃，相对湿度 5%~95% 无凝露，防护等级 IP30，适配恶劣工业环境稳定运行。
13. 支持程序段控制，可预设多段温度曲线，适配升温、恒温、降温等复杂工艺过程的自动运行需求。
14. 采用导轨式安装设计，尺寸紧凑，安装便捷，可与其他控制模块并排安装，节省控制柜空间。
15. 符合 IEC 61131-2 标准，通过 CE、UL 认证，适配全球工业应用场景，保障设备合规性与可靠性。

65040-PA52-BHK温度控制模块 英文资料：

Product Features of 65040-PA52-BHK Temperature Control Module

Adopting industrial grade high-precision temperature measurement chips, compatible with thermocouple (K/J/T/E, etc.) and RTD (Pt100/Pt1000) inputs, the measurement accuracy can reach ± 0.1 ℃, suitable for various industrial temperature measurement scenarios.

Built in adaptive PID control algorithm, supports bidirectional heating/cooling control, can automatically adjust parameters, effectively suppress overshoot and oscillation, and achieve fast constant temperature control.

The measurement temperature range covers -200 ℃~+1800 ℃, which can adapt to industrial control requirements in different temperature ranges such as low-temperature freezing and high-temperature heat treatment.

Support multi-channel temperature acquisition and control, up to 8 temperature measurement channels can be connected, and a single module can meet the needs of synchronous monitoring and independent adjustment of temperature in multiple areas.

Provide multiple output modes such as relays, solid-state relays, 4-20mA analog signals, etc., suitable for different actuators such as heaters and cooling valves, with a load capacity of AC250V/5A.

Integrated RS485 communication interface, supports Modbus RTU protocol, can communicate with PLC, HMI and upper computer, realize remote parameter setting and data acquisition.

Equipped with high brightness LED digital display and button operation area, real-time display of measured values, set values, and operating status, with intuitive and convenient parameter adjustment.

Built in multiple alarm functions, including over temperature alarm, sensor fault alarm, output abnormal alarm, etc., supporting sound and light alarm and alarm contact output, timely warning of risks.

Equipped with power-off data storage function, it can store set parameters and historical temperature records, automatically restore control status after power supply is restored, and avoid work interruption.

The three terminal electrical isolation of input, output, and power supply has strong anti-interference ability and can effectively resist electromagnetic interference in industrial sites, ensuring measurement and control stability.

Support temperature compensation function, automatically correct measurement errors caused by environmental temperature and sensor lead resistance, and improve temperature measurement accuracy.

Working temperature range -20 ℃~+60 ℃, relative humidity 5%~95%, no condensation, protection level IP30, suitable for stable operation in harsh industrial environments.

Support program segment control, can preset multiple temperature curves, adapt to the automatic operation requirements of complex process such as heating, constant temperature, and cooling.

Adopting a guide rail installation design, it is compact in size, easy to install, and can be installed side by side with other control modules, saving control cabinet space.

Compliant with IEC 61131-2 standard, certified by CE and UL, suitable for global industrial application scenarios, ensuring equipment compliance and reliability.

Summary: The 65040-P52-BHK temperature control module has the core advantages of high-precision measurement, multi-channel control, and strong anti-interference ability. It combines flexible adaptability and high reliability, and is an ideal choice for achieving precise temperature control in industries such as chemical, metallurgical, electronic, and food. It can effectively improve the stability of production processes and product quality consistency.

65040-PA52-BHK温度控制模块 产品展示
