AMAT Applied Materials 0010-29083电源供应模块

1.产 品 资 料 介 绍：

AMAT Applied Materials 0010-29083 电源供应模块

一、核心规格与技术参数

二、核心功能与设计优势

1. 多路独立输出：4 路不同规格的直流输出可同时为多种低压负载供电，无需额外搭配多个单路电源，简化设备供电系统布局，减少布线复杂度。
2. 宽幅输入与高稳定性：AC 100-240V 宽输入范围适配不同地区电网，输出纹波低至 50mV，避免电压噪声干扰传感器信号采集（如温度、压力传感器的模拟信号）。
3. 故障隔离保护：每路输出独立设置过流、过压保护，单路故障不影响其他回路，例如传感器短路仅切断对应 12VDC 回路，控制芯片的 5VDC 供电仍正常，提升设备运行容错性。
4. 无风扇低维护：自然风冷设计无需定期清洁风扇，减少维护工作量；同时避免风扇故障导致的模块过热，延长设备使用寿命（平均无故障时间 ≥50000 小时）。

AMAT Applied Materials 0010-29083电源供应模块 英文资料：

AMAT Applied Materials 0010-29083 Power Supply Module

AMAT 0010-29083 is a multi output DC power module designed specifically for low-power loads in semiconductor equipment. Its core function is to convert external AC power into stable sets of low-voltage DC outputs, providing power for precision electronic components such as sensors, control chips, and indicator lights. It is compatible with wafer process platforms such as Centura and Endura, ensuring the stability and ripple suppression capability of low-voltage load power supply, and avoiding voltage fluctuations that affect equipment signal acquisition and control accuracy.

1、 Core specifications and technical parameters

Detailed description of project specifications/indicators

Input parameter communication input: AC 100-240V (wide voltage), 50/60Hz compatible with power grid voltages in different regions around the world, no need for manual switching, suitable for cross-border deployment needs of equipment

Output parameters: 4-channel independent DC output:

-2-channel 5VDC/3A (mainly for control chips and logic circuits);

-2-channel 12VDC/2A (mainly for sensors and indicator lights), each output voltage accuracy is ± 0.5%, load adjustment rate is ≤ 1%, ripple voltage is ≤ 50mV (within 20MHz bandwidth), ensuring stable operation of precision components

When the protection function of each independent overcurrent protection (OCP), overvoltage protection (OVP), and short circuit protection (SCP) is abnormal in a single load (such as short circuit or overcurrent), only the output of that circuit is cut off, which does not affect other circuits and reduces the overall shutdown risk of the equipment

Efficiency and heat dissipation conversion efficiency ≥ 85% (at full load); Natural air cooling (fanless design) with high conversion efficiency reduces energy consumption and heat generation, fanless design avoids dust accumulation and noise, and is suitable for enclosed control cabinet environments

The working environment temperature is 0-55 ℃, humidity is ≤ 85% RH (no condensation), and it can withstand temperature fluctuations inside the equipment control cabinet. The protection level is IP20 to prevent foreign objects from falling into the module

Compact design for size and installation (120 x 80 x 30mm, length x width x height); PCB board mounted/rail mounted installation has a compact size and can be directly soldered onto the device motherboard or fixed with a 35mm rail, suitable for different installation scenarios

When the output voltage of the monitoring signal 1 power supply is stable (DC 24V/10mA, dry contact output), the "power supply normal" signal is triggered and fed back to the equipment main controller for real-time monitoring of the power status

2、 Core functions and design advantages

Multiple independent outputs: Four different specifications of DC outputs can simultaneously supply power to multiple low-voltage loads without the need for additional single power sources, simplifying the layout of equipment power supply systems and reducing wiring complexity.

Wide input and high stability: AC 100-240V wide input range is suitable for different regional power grids, with output ripple as low as 50mV, avoiding voltage noise interference in sensor signal acquisition (such as analog signals of temperature and pressure sensors).

 AMAT Applied Materials 0010-29083电源供应模块 产品展示

 产品视频
