AMAT Applied Materials 0190-02748硬度扫描仪转换模块

AMAT Applied Materials  0190-02748硬度扫描仪转换模块

1.产 品 资 料 介 绍：

核心规格

结构与原理

1. 主控单元：协议转换与数据处理，支持自动校准与补偿。
2. 隔离电路：每路传感器信号与总线之间电气隔离，抗干扰能力强。
3. 传感器接口：兼容 4‑20 mA、0‑10 V 或数字量输出硬度传感器。
4. 总线接口：通过 RJ45 连接 PLC 或上位机，支持热插拔。
5. 配置方式：通过模块按键或上位机软件设置地址、波特率、传感器类型。

AMAT Applied Materials  0190-02748硬度扫描仪转换模块 英文资料：

AMAT 0190-02748 is a Flex Scanner hardness scanner conversion module designed by Applied Materials. It is used for signal adaptation and data transmission between the hardness detection system and the upper computer in wafer manufacturing equipment. It is compatible with RS-485/RS-422 and Ethernet interfaces, and can process up to 8 channels of hardness sensor data simultaneously. It supports multi-point topology, transmission rate of 9.6 kbps~115.2 kbps, protection level IP20, and is suitable for automated hardness testing modules on platforms such as Endura and Centura.

Core specifications

Project Specification Description

Functional positioning hardness sensor signal conversion and bus transmission support Vickers, Knoop, Rockwell and other standard hardness testing

Communication interface RS-485/RS-422 or Ethernet switchable communication mode

The number of channels is 8, and each channel can be independently configured with sensor types

Transmission rate of 9.6 kbps~115.2 kbps can be configured through software, default is 19.2 kbps

Working voltage DC 24V ± 10%, typical power consumption ≤ 8W

Working temperature range of 0 ℃~50 ℃ is suitable for semiconductor workshop environment

Interface type sensor: M12 × 1 4-pin; Bus: RJ45 for easy plug and play and maintenance

Material and protective shell: ABS+PC; Protection level: IP20 dust proof, suitable for installation inside electrical control boxes

Size and installation: 120 × 80 × 35mm, 35mm rail or M4 screw compatible with AMAT standard electrical control box

Structure and Principle

This module consists of a main control unit, isolation circuit, multiple sensor interfaces, and bus interface

Main control unit: protocol conversion and data processing, supporting automatic calibration and compensation.

Isolation circuit: Each sensor signal is electrically isolated from the bus, with strong anti-interference ability.

Sensor interface: compatible with 4-20 mA, 0-10 V, or digital output hardness sensors.

Bus interface: Connected to PLC or upper computer through RJ45, supporting hot swapping.

Configuration method: Set the address, baud rate, and sensor type through module buttons or upper computer software.

 AMAT Applied Materials  0190-02748硬度扫描仪转换模块 产品展示
