AMAT Applied Materials 0190-22543网关模块
1.产 品 资 料 介 绍：
- 工业级协议全覆盖：支持半导体设备常用的各类工业协议，包括现场总线协议（如 Profinet、EtherNet/IP、Modbus RTU/TCP）、设备专用协议（如 AMAT 设备私有通信协议、SECS/GEM 半导体标准协议）及通用网络协议（如 TCP/IP、MQTT），可同时对接设备内部的 PLC、传感器、驱动器与外部的工厂 MES 系统、云端管理平台，无需额外协议转换模块，解决不同设备、系统间的 “数据孤岛” 问题。
- 高速数据传输能力：采用千兆以太网接口（传输速率 1000Mbps）与工业级通信芯片，数据转发延迟≤10ms，单模块最大并发连接数≥100，可满足半导体设备 24 小时连续运行中高频数据（如晶圆加工参数、设备状态信息）的实时传输需求，确保工艺数据无丢失、无延迟，为生产过程监控与质量追溯提供精准数据支撑。
- 双向数据交互控制：支持 “数据采集 + 指令下发” 双向交互，既能实时采集设备运行参数（如温度、压力、晶圆传输进度）并上传至管理系统，也能接收系统下发的控制指令（如工艺程序切换、设备启停信号）并转发至设备执行模块，实现对半导体设备的远程监控与精准控制，提升生产自动化水平。
- 数据传输加密：采用 AES-256 对称加密算法与 RSA 非对称加密算法，对设备与系统间传输的所有数据（包括工艺参数、控制指令）进行端到端加密，防止数据在传输过程中被窃取或篡改；同时支持 SSL/TLS 安全通信协议，保障网络传输链路安全，符合半导体行业数据保密标准（如 ISO 27001 信息安全管理体系）。
AMAT Applied Materials 0190-22543网关模块 英文资料：
1、 Multi protocol compatible data exchange: Connecting semiconductor device data links
As the "data translation hub" of semiconductor devices, the 0190-22543 gateway module is based on the ability to adapt protocols to all scenarios, achieving seamless data interconnection between internal modules and external systems of the device
Full coverage of industrial level protocols: Supports various industrial protocols commonly used in semiconductor devices, including fieldbus protocols (such as Profinet, EtherNet/IP, Modbus RTU/TCP), device specific protocols (such as AMAT device private communication protocol, SECS/GEM semiconductor standard protocol), and general network protocols (such as TCP/IP, MQTT). It can simultaneously interface with internal PLCs, sensors, drivers, external factory MES systems, and cloud management platforms without the need for additional protocol conversion modules, solving the problem of "data silos" between different devices and systems.
High speed data transmission capability: using Gigabit Ethernet interface (transmission rate 1000Mbps) and industrial grade communication chip, data forwarding delay ≤ 10ms, maximum concurrent connections per module ≥ 100, can meet the real-time transmission requirements of high-frequency data (such as wafer processing parameters and equipment status information) in 24-hour continuous operation of semiconductor equipment, ensuring no loss or delay of process data, and providing accurate data support for production process monitoring and quality traceability.
Bidirectional data exchange control: supports "data acquisition+instruction issuance" bidirectional interaction, which can not only real-time collect equipment operating parameters (such as temperature, pressure, wafer transfer progress) and upload them to the management system, but also receive control instructions issued by the system (such as process program switching, equipment start stop signals) and forward them to the equipment execution module, realizing remote monitoring and precise control of semiconductor equipment, and improving the level of production automation.
2、 High reliability network security protection: safeguarding semiconductor core data
In response to the high confidentiality of process data and high security of equipment control in the semiconductor industry, this gateway module has built a multi-level security protection system:
Data transmission encryption: AES-256 symmetric encryption algorithm and RSA asymmetric encryption algorithm are used to encrypt all data (including process parameters and control instructions) transmitted between devices and systems end-to-end, preventing data from being stolen or tampered with during transmission; Simultaneously supporting SSL/TLS secure communication protocols, ensuring the security of network transmission links, and complying with data confidentiality standards in the semiconductor industry (such as ISO 27001 Information Security Management System).
AMAT Applied Materials 0190-22543网关模块 产品展示
