P0914TN FBM211编程式输入模块

1.产 品 资 料 介 绍：

P0914TN FBM211 编程式模拟输入模块

1. 属于 Foxboro I/A Series DCS 系统，为16 通道 0–20mA 差分模拟输入模块（编程式 AI）。
2. 每 8 通道一组电气隔离，通道与系统、地全隔离，抗干扰、防地环流，适配复杂工业现场。
3. 输入范围0–20.4mA DC，兼容标准4–20mA变送器、二线制仪表与自供电信号源。
4. 精度 **±0.03% 量程 **，温度系数 **±50ppm/℃**，满足高精度过程测量需求。
5. 内置可编程信号处理，支持转换时间、变化率限制、滤波与平均算法配置。
6. 支持二线制仪表供电，简化现场布线，适配压力、流量、液位等变送器。
7. 24VDC 供电，支持冗余双电源，最大功耗低，供电稳定可靠。
8. 配备LED 状态指示灯，直观显示模块运行、通信及通道状态，便于快速诊断。
9. 支持冗余 2Mbps 现场总线通信，保障与控制器稳定数据交互。
10. 支持在线热插拔，维护无需断电拆线，不影响系统连续运行。
11. 工业级宽温设计，工作温度 **-40℃~+85℃**，满足 G3 严酷工业环境标准。
12. 模块化结构，DIN 导轨安装，配合专用端子组件，部署与接线便捷。
13. 无缝集成 I/A Series 控制系统，支持在线诊断、状态监控与趋势记录。
14. 适用于石油化工、电力、冶金、水处理等行业的高精度模拟量采集与过程控制场景。

P0914TN FBM211编程式输入模块 英文资料：

P0914TN FBM211 Programmable Analog Input Module

Belonging to the Foxboro I/A Series DCS system, it is a 16 channel 0-20mA differential analog input module (programmed AI).

Each group of 8 channels is electrically isolated, and the channels are fully isolated from the system and ground, with anti-interference and anti ground circulation capabilities, suitable for complex industrial sites.

Input range 0-20.4mA DC, compatible with standard 4-20mA transmitters, two-wire instruments, and self supplied electrical signal sources.

Accuracy * * ± 0.03% range * *, temperature coefficient * * ± 50ppm/℃ * *, meeting the requirements of high-precision process measurement.

Built in programmable signal processing, supporting conversion time, rate of change limitation, filtering, and averaging algorithm configuration.

Support two-wire instrument power supply, simplify on-site wiring, and adapt to pressure, flow, liquid level and other transmitters.

24VDC power supply, supporting redundant dual power supply, low maximum power consumption, stable and reliable power supply.

Equipped with LED status indicator lights, it intuitively displays the operation, communication, and channel status of the module, facilitating quick diagnosis.

Support redundant 2Mbps fieldbus communication to ensure stable data exchange with the controller.

Support online hot plugging, maintenance does not require power outage or disconnection, and does not affect the continuous operation of the system.

Industrial grade wide temperature design, working temperature range of * * -40 ℃~+85 ℃ * *, meeting the strict industrial environment standards of G3.

Modular structure, DIN rail installation, combined with dedicated terminal components, easy deployment and wiring.

Seamless integration of I/A Series control system, supporting online diagnosis, status monitoring, and trend recording.

Suitable for high-precision analog data acquisition and process control scenarios in industries such as petrochemicals, power, metallurgy, and water treatment.

This module, with its core advantages of high isolation, high precision, programmability, and high reliability, is a key component for accurate acquisition and intelligent processing of analog signals in industrial DCS systems, which can effectively improve process control accuracy and system stability.

P0914TN FBM211编程式输入模块 产品展示
