P0914TR FBM217隔离监视器

1.产 品 资 料 介 绍：

P0914TR FBM217 隔离监视器（电压 / 离散输入模块）

1. 属于 Foxboro I/A Series DCS 系统，为32 通道组隔离离散输入 / 电压监视器模块。
2. 采用组隔离设计，通道组与系统、地全隔离，耐受 600VAC/1min，强抗干扰、防地环流。
3. 支持15–60VDC、120VAC/125VDC、240VAC多电压等级输入，适配干接点 / 湿接点 / 电压监测场景。
4. 单通道典型输入电流2.2mA@30VDC，导通阈值 15–30VDC、关断阈值 0–5VDC，信号识别精准。
5. 内置信号滤波与消抖，可软件配置滤波参数，提升复杂现场信号稳定性。
6. 24VDC 冗余供电，最大功耗 3W，供电安全可靠。
7. 配备LED 状态指示灯，直观显示模块运行、通信及通道输入状态，便于快速诊断。
8. 支持冗余 2Mbps 现场总线通信，保障与 FCM/FCP 控制器稳定数据交互。
9. 支持在线热插拔，维护无需断电拆线，不影响系统连续运行。
10. 工业级宽温设计，工作温度 **-40℃~+85℃**，满足 G3 严酷工业环境标准。
11. 模块化结构，DIN 导轨安装，搭配 P0914TR 端子组件，部署与接线便捷。
12. 无缝集成 I/A Series 控制系统，支持在线诊断、状态监控与 SOE 事件顺序记录。
13. 适用于石油化工、电力、冶金、水处理等行业的开关量采集、电压监测、设备状态反馈与安全联锁场景。

P0914TR FBM217隔离监视器 英文资料：

P0914TR FBM217 Isolation Monitor (Voltage/Discrete Input Module)

Belonging to the Foxboro I/A Series DCS system, it is a 32 channel group isolated discrete input/voltage monitor module.

Adopting a group isolation design, the channel group is fully isolated from the system and ground, with a tolerance of 600VAC/1min, strong anti-interference, and anti ground circulation.

Supports multi voltage level inputs of 15-60VDC, 120VAC/125VDC, and 240VAC, suitable for dry contact/wet contact/voltage monitoring scenarios.

Single channel typical input current 2.2mA@30VDC The conduction threshold is 15-30VDC, and the turn off threshold is 0-5VDC, ensuring accurate signal recognition.

Built in signal filtering and stabilization, with software configurable filtering parameters to enhance the stability of complex on-site signals.

24VDC redundant power supply, maximum power consumption of 3W, safe and reliable power supply.

Equipped with LED status indicator lights, it intuitively displays the operation, communication, and channel input status of the module, facilitating quick diagnosis.

Support redundant 2Mbps fieldbus communication to ensure stable data exchange with FCM/FCP controllers.

Support online hot plugging, maintenance does not require power outage or disconnection, and does not affect the continuous operation of the system.

Industrial grade wide temperature design, working temperature range of * * -40 ℃~+85 ℃ * *, meeting the strict industrial environment standards of G3.

Modular structure, DIN rail installation, paired with P0914TR terminal assembly, easy deployment and wiring.

Seamless integration of I/A Series control system, supporting online diagnosis, status monitoring, and SOE event sequence recording.

Suitable for switch quantity collection, voltage monitoring, equipment status feedback, and safety interlocking scenarios in industries such as petrochemicals, power, metallurgy, and water treatment.

This module, with its core advantages of 32 channel high density, group isolation high reliability, multi voltage compatibility, and easy maintenance, is a key component for discrete signal and voltage monitoring in industrial DCS systems. It can efficiently meet the needs of large-scale on-site signal acquisition and safety monitoring.

P0914TR FBM217隔离监视器 产品展示
