1.产 品 资 料 介 绍：
P0916JQ 隔离模块（Foxboro I/A Series）
属于 Foxboro I/A Series DCS 系统，为8 通道隔离数字输入模块（FBM 系列）。
每通道独立电气全隔离，通道间 / 通道对地隔离耐压高，抗干扰、防地环流，适配复杂工业现场。
支持24VDC 干接点 / 湿接点数字信号输入，兼容现场开关、限位、报警等设备信号。
输入信号滤波消抖，可软件配置滤波参数，提升信号稳定性与可靠性。
24VDC 供电，支持冗余双电源，最大功耗低，供电安全稳定。
配备LED 状态指示灯，直观显示模块运行、通信及各通道输入状态，便于快速诊断。
支持在线热插拔，维护无需断电拆线，不影响系统连续运行。
工业级宽温设计，工作温度 **-40℃~+85℃**，满足 G3 严酷工业环境标准。
模块化结构，DIN 导轨安装，配合专用端子组件，部署与接线便捷。
无缝集成 I/A Series 控制系统，支持在线诊断、状态监控与 SOE 事件顺序记录。
符合 SIL 2 安全完整性等级，适用于安全关键型过程控制场景。
适用于石油化工、电力、冶金、水处理等行业的开关量信号采集与安全联锁场景。
该模块凭借高隔离、高可靠、易维护、安全合规等核心优势，是工业 DCS 系统中数字信号采集的关键部件，可有效保障现场信号稳定传输与系统安全运行。
P0916JQ隔离模块 英文资料：
P0916JQ Isolation Module (Foxboro I/A Series)
Belonging to the Foxboro I/A Series DCS system, it is an 8-channel isolated digital input module (FBM series).
Each channel is independently electrically isolated, with high voltage resistance between channels/channels to ground isolation, anti-interference, and anti ground circulation, suitable for complex industrial sites.
Supports 24VDC dry/wet contact digital signal input, compatible with on-site switch, limit, alarm and other equipment signals.
Input signal filtering and stabilization, with software configurable filtering parameters to enhance signal stability and reliability.
24VDC power supply, supporting redundant dual power supply, low maximum power consumption, safe and stable power supply.
Equipped with LED status indicator lights, it intuitively displays the operation, communication, and input status of each channel of the module, facilitating quick diagnosis.
Support online hot plugging, maintenance does not require power outage or disconnection, and does not affect the continuous operation of the system.
Industrial grade wide temperature design, working temperature range of * * -40 ℃~+85 ℃ * *, meeting the strict industrial environment standards of G3.
Modular structure, DIN rail installation, combined with dedicated terminal components, easy deployment and wiring.
Seamless integration of I/A Series control system, supporting online diagnosis, status monitoring, and SOE event sequence recording.
Compliant with SIL 2 safety integrity level, suitable for safety critical process control scenarios.
Suitable for switch signal acquisition and safety interlocking scenarios in industries such as petrochemicals, power, metallurgy, and water treatment.
This module, with its core advantages of high isolation, high reliability, easy maintenance, and safety compliance, is a key component for digital signal acquisition in industrial DCS systems, which can effectively ensure stable transmission of on-site signals and safe operation of the system.
P0916JQ隔离模块 产品展示
