TRICONEX 3700A分析模块
1.产 品 资 料 介 绍：
- 高精度数据采集：能精准采集模拟量信号，测量误差小于 ±0.1%，适配压力、温度等工业参数监测，数据准确度满足油气、化工等高精度需求。
- 多信号类型兼容：支持 4-20mA、0-10V 等常见工业信号，不用额外加信号转换器，可直接对接传感器、变送器，适配多种监测场景。
- 三重冗余保稳定：采用 TMR 架构，三个独立通道同步处理数据，单个通道故障不影响分析结果，符合 SIL 3 安全标准，适合高危环境使用。
- 快速分析响应：数据处理延迟低至毫秒级，能实时输出分析结果，异常参数出现时，可快速触发预警，比普通模块响应速度快 20%。
- 自带故障诊断：实时监测自身硬件状态，通道异常、信号失真时会主动报警，还能记录故障信息，后期排查原因更便捷，减少维修时间。
- 抗干扰能力强：信号通道具备 1500V DC 隔离保护，能抵御电磁辐射、电压波动，在电机多、变频器密集的车间，数据传输仍稳定。
- 宽温环境适配：工作温度范围 - 40℃至 70℃，电路板做了防潮处理，高湿度、多粉尘环境下也能正常工作，不用额外装防护设备。
- 支持在线维护：可带电插拔，系统运行时能更换模块或校准参数，不用停线，维护过程不影响生产，提升设备利用率。
- 灵活对接系统：能无缝接入 TRICONEX TMR 安全控制系统，支持 Modbus TCP/IP 协议，和 PLC、监控平台连接简单，不用大量修改程序。
- 高耐用设计：外壳用防腐蚀金属材质，关键元器件选工业级产品，平均无故障工作时间超 15 万小时，适合长期连续监测场景。
TRICONEX 3700A分析模块 英文资料：
High precision data collection: It can accurately collect analog signals with a measurement error of less than ± 0.1%, suitable for monitoring industrial parameters such as pressure and temperature, and the data accuracy meets the high-precision requirements of oil and gas, chemical and other industries.
Multi signal type compatibility: Supports common industrial signals such as 4-20mA and 0-10V, without the need for additional signal converters. It can directly interface with sensors and transmitters and adapt to various monitoring scenarios.
Triple redundancy ensures stability: adopting TMR architecture, three independent channels synchronously process data, and a single channel failure does not affect the analysis results. It meets SIL 3 safety standards and is suitable for use in high-risk environments.
Quick analysis response: With data processing latency as low as milliseconds, it can output analysis results in real-time. When abnormal parameters occur, it can quickly trigger warnings, which is 20% faster than the response speed of ordinary modules.
Equipped with fault diagnosis: Real time monitoring of its own hardware status, it will actively alarm when there are channel abnormalities or signal distortions, and can also record fault information, making it more convenient to investigate the cause later and reducing maintenance time.
Strong anti-interference ability: The signal channel has 1500V DC isolation protection, which can resist electromagnetic radiation and voltage fluctuations. In workshops with many motors and dense frequency converters, data transmission is still stable.
Wide temperature environment adaptation: The working temperature range is from 40 ℃ to 70 ℃. The circuit board has undergone moisture-proof treatment and can work normally even in high humidity and dusty environments without the need for additional protective equipment.
Support online maintenance: It can be plugged and unplugged with power, and modules or parameters can be replaced or calibrated during system operation without stopping the line. The maintenance process does not affect production and improves equipment utilization.
Flexible docking system: It can seamlessly integrate with the TRICONEX TMR safety control system, support Modbus TCP/IP protocol, and is easy to connect with PLCs and monitoring platforms without extensive program modifications.
High durability design: The casing is made of corrosion-resistant metal material, and key components are selected from industrial grade products. The average time between failures exceeds 150000 hours, making it suitable for long-term continuous monitoring scenarios.
TRICONEX 3700A分析模块 产品展示
产品视频
