IC697CPU780处理器模块

1.产 品 资 料 介 绍：

IC697CPU780 处理器模块

1. 搭载 Intel 80386DX 处理器，主频 16MHz，运算性能强劲。
2. 布尔指令执行速度达 0.4 微秒 / 条，实时响应快。
3. 支持热备冗余配置，主备 CPU 自动同步，实现无扰切换。
4. 最大支持 12K 离散 I/O 与 8K 模拟 I/O，适配超大型控制规模。
5. 内存可扩展，支持最高 512KB 电池备份 RAM 与 512KB 闪存。
6. 具备浮点运算能力，轻松应对复杂工艺的精准计算。
7. 单槽位设计，需安装在机架第 1 槽，安装规范且节省空间。
8. 配备 4 个 LED 状态指示灯，直观显示模块健康、运行、输出等状态。
9. 支持在线编程与修改，无需停机即可完成程序更新。
10. 内置 RS-485 通信接口，兼容 SNP 协议，方便连接上位机与编程设备。
11. 采用钥匙开关 + 软件密码双重保护，防止程序与配置被误改。
12. 符合 VME C.1 总线标准，背板通信稳定，扩展兼容性强。
13. 工业级宽温设计，工作温度覆盖 0℃至 60℃，适应恶劣工厂环境。
14. 内存板带校验功能，可实时检测并上报奇偶错误，提升数据可靠性。
15. 广泛用于电力、化工、冶金等关键流程工业，保障系统连续运行。

IC697CPU780处理器模块 英文资料：

IC697 CPU 780 processor module

IC697CP780 is a high availability hot standby redundant CPU module from GE Fanuc 90-70 series, designed specifically for critical industrial control scenarios. It features disturbance free switching and powerful computing power, and is suitable for large-scale production lines, process industries, and other automation systems that require high continuity.

Equipped with Intel 80386DX processor, with a main frequency of 16MHz and strong computing performance.

Boolean instruction execution speed reaches 0.4 microseconds per instruction, with fast real-time response.

Support hot standby redundancy configuration, automatic synchronization of primary and backup CPUs, achieving seamless switching.

Supports up to 12K discrete I/O and 8K analog I/O, suitable for ultra large control scales.

Scalable memory, supporting up to 512KB battery backup RAM and 512KB flash memory.

Capable of floating-point operations, easily handling precise calculations for complex processes.

Single slot design, to be installed in the first slot of the rack, with standardized installation and space saving.

Equipped with 4 LED status indicator lights, it intuitively displays the health, operation, output and other status of the module.

Support online programming and modification, program updates can be completed without downtime.

Built in RS-485 communication interface, compatible with SNP protocol, convenient for connecting upper computer and programming equipment.

Adopting dual protection of key switch and software password to prevent program and configuration from being mistakenly changed.

Compliant with VME C1 bus standard, with stable backplane communication and strong expansion compatibility.

Industrial grade wide temperature design, with a working temperature range of 0 ℃ to 60 ℃, suitable for harsh factory environments.

The memory board comes with a verification function, which can detect and report parity errors in real time, improving data reliability.

Widely used in key process industries such as power, chemical, and metallurgical industries to ensure continuous system operation.

The IC697CP780, with its core advantages of redundancy, high availability, strong computing power, and good scalability, has become the main CPU for handling critical control tasks in the 90-70 series, providing uninterrupted and stable computing power support for industrial automation systems.

IC697CPU780处理器模块 产品展示
