1.产 品 资 料 介 绍：
- 安装 YASKAWA SGDB-20VDY85 时需固定在散热良好的金属支架上，预留≥10cm 散热空间。
- 接线前确认电源电压与 SGDB-20VDY85 额定输入匹配，避免过压烧毁内部模块。
- YASKAWA SGDB-20VDY85 支持位置 / 速度 / 转矩控制模式，切换时需重启控制器生效。
- 主回路接线需选用≥2.5mm² 铜导线，端子紧固时遵循规定扭矩，防止接触不良。
- 定期备份 SGDB-20VDY85 的参数配置，避免误操作导致参数丢失影响运行。
- 编码器信号线需远离动力电缆布线，减少电磁干扰对 YASKAWA SGDB-20VDY85 信号检测的影响。
- 运行中若 SGDB-20VDY85 报过流故障，需先检查电机绕组绝缘及电缆破损情况。
- 清洁控制器时需断开电源，用干燥抹布擦拭外壳，禁止用水或有机溶剂。
- YASKAWA SGDB-20VDY85 的制动电阻需按手册规格选配，避免容量不足引发过热。
- 定期检查散热风扇运行状态，若停转需及时更换，保障 SGDB-20VDY85 散热效率。
- 调整电子齿轮比时，需结合电机分辨率与负载需求，确保 SGDB-20VDY85 定位精度。
- 禁止在 SGDB-20VDY85 运行中插拔连接器，防止瞬时电流损坏接口芯片。
- 环境湿度需控制在 20%-85%（无凝露），避免湿气导致 YASKAWA SGDB-20VDY85 内部短路。
- 故障报警后需先清除报警代码，排查根源后再重启，禁止强制复位运行。
- 长期停用前需断开电源，每 3 个月通电预热 30 分钟，保护 SGDB-20VDY85 内部电容。
SGDB-20VDY85伺服控制器 英文资料：
When installing YASKAWA SGDB-20VDY85, it needs to be fixed on a metal bracket with good heat dissipation, leaving a heat dissipation space of ≥ 10cm.
Before wiring, confirm that the power supply voltage matches the rated input of SGDB-20VDY85 to avoid damaging the internal module due to overvoltage.
YASKAWA SGDB-20VDY85 supports position/speed/torque control modes, and the controller needs to be restarted to take effect when switching.
The main circuit wiring should use copper wires with an area of ≥ 2.5mm ², and the terminals should be tightened according to the specified torque to prevent poor contact.
Regularly backup the parameter configuration of SGDB-20VDY85 to avoid parameter loss caused by misoperation and affecting operation.
The encoder signal line should be routed away from the power cable to reduce the impact of electromagnetic interference on YASKAWA SGDB-20VDY85 signal detection.
If SGDB-20VDY85 reports overcurrent fault during operation, it is necessary to first check the insulation of the motor winding and cable damage.
When cleaning the controller, disconnect the power and wipe the outer shell with a dry cloth. Do not use water or organic solvents.
The braking resistor of YASKAWA SGDB-20VDY85 needs to be selected according to the manual specifications to avoid overheating caused by insufficient capacity.
Regularly check the operation status of the cooling fan, and ｒｅｐｌａｃｅ it promptly if it stops running to ensure the cooling efficiency of SGDB-20VDY85.
When adjusting the electronic gear ratio, it is necessary to combine the motor resolution and load requirements to ensure the positioning accuracy of SGDB-20VDY85.
Do not plug or unplug connectors during the operation of SGDB-20VDY85 to prevent instantaneous current from damaging the interface chip.
The environmental humidity should be controlled between 20% and 85% (without condensation) to avoid moisture causing internal short circuits in YASKAWA SGDB-20VDY85.
After the fault alarm is triggered, the alarm code should be cleared first, the root cause should be investigated before restarting, and forced reset operation is prohibited.
Before long-term shutdown, the power should be disconnected and preheated for 30 minutes every 3 months to protect the internal capacitor of SGDB-20VDY85.
Summary: The stable operation core of YASKAWA SGDB-20VDY85 servo controller lies in standardized installation, correct wiring, parameter backup, and environmental adaptation, with a focus on heat dissipation protection, electromagnetic compatibility, and fault compliance handling. It fully utilizes its precise control and high reliability advantages of 2kW power level to extend the overall service life of the equipment.
