1.产 品 资 料 介 绍：
- 安装 AB 2098-DSD-020X 需采用面板安装方式，确保散热路径通畅，预留≥8cm 通风空间。
- 接线前确认输入电压为 100-240VAC 单相，与 AB 2098-DSD-020X 额定输入匹配。
- AB 2098-DSD-020X 支持索引、点对点及协调运动控制，切换模式需通过 Ultraware 软件配置。
- 主回路电缆选用≥1.5mm² 铜导线，端子紧固扭矩控制在 180-220N・cm，防止接触不良。
- 定期通过 RSNetWorx 软件备份 AB 2098-DSD-020X 参数，避免误操作导致配置丢失。
- DeviceNet 通信线需单独布线并规范终端电阻，减少对 AB 2098-DSD-020X 信号传输的干扰。
- 运行中若 AB 2098-DSD-020X 报过流故障，先检查电机绕组绝缘及 UVW 相序接线。
- 清洁驱动器时需断开电源，用干燥抹布擦拭外壳，禁止触碰内部电路板及散热部件。
- AB 2098-DSD-020X 为被动散热设计，需保持安装面清洁，避免覆盖异物影响散热。
- 定期检查编码器接线与型号匹配性，确保与 AB 2098-DSD-020X 参数设置一致。
- 环境温度控制在 - 20℃至 + 60℃，湿度 5%-95%（无凝露），适配 AB 2098-DSD-020X 工作范围。
- 禁止在驱动器运行时插拔连接器，防止瞬时电流损坏 AB 2098-DSD-020X 接口芯片。
- 选配熔断器需符合 LPJ-20SP（Class J）或 FNQ-R-20（Class CC）规格，保障电路安全。
- 调整运动曲线参数时，需结合 AB 2098-DSD-020X 30A 峰值电流限制，避免过载。
- 长期闲置后重启，需先将 AB 2098-DSD-020X 置于室温回温，确认无凝露后再通电。
2098-DSD-020X伺服驱动器 英文资料：
The installation of AB 2098-DSD-020X requires a panel installation method to ensure a smooth heat dissipation path and reserve a ventilation space of ≥ 8cm.
Before wiring, confirm that the input voltage is 100-240VAC single-phase and matches the rated input of AB 2098-DSD-020X.
AB 2098-DSD-020X supports indexing, point-to-point, and coordinated motion control, and mode switching requires configuration through Ultraware software.
The main circuit cable uses copper wires with an area of ≥ 1.5mm ², and the terminal tightening torque is controlled between 180-220N · cm to prevent poor contact.
Regularly backup AB 2098-DSD-020X parameters through RSNetWorx software to avoid configuration loss caused by misoperation.
The DeviceNet communication line needs to be wired separately and the terminal resistance should be standardized to reduce interference with AB 2098-DSD-020X signal transmission.
If AB 2098-DSD-020X reports an overcurrent fault during operation, first check the motor winding insulation and UVW phase sequence wiring.
When cleaning the drive, disconnect the power and wipe the outer shell with a dry cloth. Do not touch the internal circuit board and heat dissipation components.
AB 2098-DSD-020X is designed for passive heat dissipation, and the installation surface needs to be kept clean to avoid covering foreign objects that may affect heat dissipation.
Regularly check the encoder wiring and model matching to ensure consistency with the AB 2098-DSD-020X parameter settings.
The ambient temperature is controlled between -20 ℃ and+60 ℃, with a humidity of 5% -95% (no condensation), suitable for the working range of AB 2098-DSD-020X.
Do not plug or unplug connectors while the drive is running to prevent instantaneous current damage to the AB 2098-DSD-020X interface chip.
Optional fuses must comply with LPJ-20SP (Class J) or FNQ-R-20 (Class CC) specifications to ensure circuit safety.
When adjusting the parameters of the motion curve, it is necessary to combine AB 2098-DSD-020X 30A peak current limit to avoid overload.
After being idle for a long time and restarting, AB 2098-DSD-020X needs to be placed at room temperature and warmed up to confirm that there is no condensation before powering on.
Summary: The stable operation of AB 2098-DSD-020X servo drive requires a focus on standardized installation, compliant wiring, software configuration, and environmental adaptation, with a particular emphasis on communication line wiring, heat dissipation assurance, and root cause troubleshooting. It fully leverages its DeviceNet networking advantages and precise control performance at 2kW power levels to extend equipment lifespan.
2098-DSD-020X伺服驱动器 产品展示
产品视频
