01-25-03508处理器模块

1.产 品 资 料 介 绍：

01-25-03508 处理器模块使用注意事项

1. 模块拆封、安装全程佩戴防静电手环与防静电手套，防止静电击穿核心运算芯片。
2. 安装时对准主板插槽金手指位置轻推到位，扣紧固定卡扣，严禁暴力插拔或晃动模块。
3. 接线前核对端子引脚定义，严格区分电源、通信、I/O 信号端口，杜绝混接导致模块烧毁。
4. 供电电源需匹配模块额定电压，接线时确认正负极性无误，无短路隐患后再上电。
5. 通信线缆选用屏蔽双绞线，与动力线缆分开布线，间距不小于 20cm，减少电磁干扰。
6. 连接扩展模块或外设时，需在断电状态下操作，确保通信总线接头插紧并锁紧固定螺丝。
7. 模块运行环境温度控制在 - 5℃~60℃，相对湿度保持在 5%~95% 无凝露，远离热源与腐蚀性气体。
8. 下载程序前备份原有程序与参数，避免误操作覆盖关键控制逻辑，影响系统运行。
9. 首次上电后观察运行指示灯状态，指示灯正常闪烁且无故障报警，再进行程序调试。
10. 调试时采用分步加载方式，先测试基础通信功能，再逐步启用运算与控制模块。
11. 禁止在模块运行过程中插拔任何线缆或扩展模块，防止瞬时电流冲击损坏硬件。
12. 定期检查模块接线端子与散热风扇，拧紧松动螺丝，清理风扇滤网灰尘，保障散热通畅。
13. 清洁模块表面时需先断电，用干燥软毛刷轻扫灰尘，避免液体进入模块内部。
14. 长期停机时断开模块供电电源，做好防尘防潮包装，放置在干燥通风的环境中存储。
15. 非专业维修人员严禁拆解模块外壳，出现故障时记录故障代码与指示灯状态，联系厂家处理。

01-25-03508处理器模块 英文资料：

01-25-03508 Precautions for using processor module

Wear anti-static wristbands and gloves throughout the module unpacking and installation process to prevent static electricity from penetrating the core computing chip.

During installation, align with the gold finger position on the motherboard slot and gently push it into place. Tighten the fixing buckle and do not forcefully ｉｎｓｅｒｔ or shake the module.

Before wiring, check the terminal pin definitions and strictly distinguish between power, communication, and I/O signal ports to prevent module burnout caused by mixing.

The power supply needs to match the rated voltage of the module. When wiring, confirm that the positive and negative polarities are correct and there is no short circuit hazard before powering on.

Shielded twisted pair cables are selected for communication cables, which are routed separately from power cables with a spacing of no less than 20cm to reduce electromagnetic interference.

When connecting expansion modules or peripherals, it is necessary to operate in a power-off state to ensure that the communication bus connector is securely plugged in and the fixing screws are locked.

The operating environment temperature of the module is controlled at -5 ℃~60 ℃, the relative humidity is maintained at 5%~95% without condensation, and it is kept away from heat sources and corrosive gases.

Before downloading the program, backup the original program and parameters to avoid accidental operations that may overwrite critical control logic and affect system operation.

After the first power on, observe the status of the running indicator light, which flashes normally without any fault alarms, and then perform program debugging.

During debugging, a step-by-step loading method is used to test the basic communication functions first, and then gradually enable the operation and control modules.

Do not plug or unplug any cables or expand modules during module operation to prevent hardware damage from transient current surges.

Regularly check the module wiring terminals and cooling fan, tighten loose screws, clean the fan filter dust, and ensure smooth heat dissipation.

When cleaning the surface of the module, power off first and use a dry soft bristled brush to gently sweep away dust to prevent liquids from entering the interior of the module.

Disconnect the power supply of the module during long-term shutdown, pack it with dust-proof and moisture-proof materials, and store it in a dry and ventilated environment.

Non professional maintenance personnel are strictly prohibited from disassembling the module casing. When a fault occurs, record the fault code and indicator light status, and contact the manufacturer for handling.

Summary: The use of the 01-25-03508 processor module requires special attention to anti-static protection, wiring specifications, and anti-interference wiring. The program download and debugging should follow the step-by-step operation principle, and daily maintenance should focus on heat dissipation and terminal fastening to avoid risky behaviors such as live plugging and illegal disassembly, which can ensure the stability of module operation and system control accuracy.
