0190-62069电源供应模块

1.产 品 资 料 介 绍：

0190-62069 电源供应模块使用注意事项

1. 模块拆封、安装全程佩戴防静电手环，防止静电损坏内部电源管理芯片和滤波电容。
2. 安装时对准设备背板卡槽平稳推入，扣紧两侧固定卡扣，严禁暴力插拔导致金手指磨损或变形。
3. 接线前核对端子标识，严格区分交流输入、直流输出及接地端口，杜绝端口接错造成模块烧毁。
4. 输入电源需符合模块额定电压范围，接入前用万用表检测电压稳定性，确认无过压、欠压情况后再上电。
5. 输出端连接负载前，核算负载总功率，确保不超过模块额定输出功率，禁止超载运行触发保护机制。
6. 接线时按规定力矩拧紧端子螺丝，避免松动引发接触不良，出现端子发烫、供电中断等问题。
7. 模块运行环境温度控制在 - 10℃~55℃，相对湿度保持在 10%~90% 无凝露，远离高温热源和腐蚀性气体。
8. 确保模块散热格栅无异物遮挡，散热风扇运行时无异常异响，保障热量及时散发防止模块过热。
9. 多模块并联冗余供电时，需严格按照手册要求连接均流线，确保电流均衡分配，避免单模块过载损坏。
10. 上电后先观察运行指示灯状态，指示灯正常点亮且无故障报警提示，再逐步接入负载设备。
11. 禁止在模块运行过程中插拔输入或输出线缆，防止瞬时浪涌电流冲击内部电路，造成元件损坏。
12. 定期检测模块输入输出电压，若电压波动超出允许范围，立即断电排查故障原因并及时处理。
13. 清洁模块表面及散热风扇时，需先断开电源，用干燥软毛刷轻扫灰尘，禁止使用液体清洁剂。
14. 长期闲置时，断开模块所有接线，放入防静电包装袋中，置于干燥、通风、防尘的环境存储。
15. 非专业维修人员严禁拆解模块外壳，出现故障时记录指示灯状态和故障现象，联系厂家售后处理。

0190-62069电源供应模块 英文资料：

0190-62069 Precautions for using power supply module

Wear an anti-static wristband throughout the module unpacking and installation process to prevent static electricity from damaging the internal power management chip and filtering capacitor.

During installation, align the device backplane slot and smoothly push it in, fasten the fixed buckles on both sides, and strictly prohibit violent insertion and removal that may cause wear or deformation of the golden fingers.

Before wiring, check the terminal identification and strictly distinguish between AC input, DC output, and grounding ports to prevent module burnout caused by incorrect port connections.

The input power supply must comply with the rated voltage range of the module. Before connection, use a multimeter to check the voltage stability and confirm that there is no overvoltage or undervoltage before powering on.

Before connecting the output end to the load, calculate the total power of the load to ensure that it does not exceed the rated output power of the module, and prohibit overloading operation to trigger the protection mechanism.

When wiring, tighten the terminal screws according to the specified torque to avoid loosening and causing poor contact, such as terminal overheating and power interruption.

The operating environment temperature of the module is controlled between -10 ℃~55 ℃, the relative humidity is maintained at 10%~90% without condensation, and it is kept away from high temperature heat sources and corrosive gases.

Ensure that the module's heat dissipation grille is unobstructed by foreign objects, and that the cooling fan operates without any abnormal noise, ensuring timely heat dissipation and preventing module overheating.

When multiple modules are connected in parallel for redundant power supply, it is necessary to strictly follow the manual requirements to connect the current balancing line, ensure balanced current distribution, and avoid single module overload damage.

After powering on, first observe the status of the running indicator light. The indicator light should light up normally without any fault alarm prompts, and then gradually connect the load device.

Do not plug or unplug input or output cables during module operation to prevent transient surge currents from impacting internal circuits and causing component damage.

Regularly check the input and output voltage of the module. If the voltage fluctuation exceeds the allowable range, immediately cut off the power to investigate the cause of the fault and handle it in a timely manner.

When cleaning the surface of the module and the cooling fan, the power should be disconnected first, and a dry soft bristled brush should be used to gently sweep away dust. The use of liquid cleaning agents is prohibited.

When idle for a long time, disconnect all wiring of the module, place it in an anti-static packaging bag, and store it in a dry, ventilated, and dust-proof environment.

Non professional maintenance personnel are strictly prohibited from disassembling the module casing. When a fault occurs, record the status of the indicator light and the fault phenomenon, and contact the manufacturer's after-sales service for handling.

Summary: The use of the 0190-62069 power supply module should focus on anti-static protection, port wiring specifications, and load power matching. Daily maintenance should pay attention to heat dissipation, cleaning, and voltage monitoring to avoid risk operations such as overload operation and live plugging, which can effectively ensure the stability of module power supply and service life.

0190-62069电源供应模块 产品展示
