0190-22543输入输出模块

1.产 品 资 料 介 绍：

0190-22543 输入输出模块产品特点

1. 集成 16 路数字量输入 + 16 路继电器输出，支持干 / 湿接点输入与 AC220V/DC24V 负载驱动，满足多设备集中控制需求。
2. 输入通道采用光电隔离技术，隔离电压≥2500VAC，可有效抵御现场电磁干扰，保障信号采集精度。
3. 输出继电器触点额定电流 10A，支持脉冲 / 电平两种控制方式，可直接驱动接触器、电磁阀等大功率执行元件。
4. 兼容 Modbus-RTU 与 Profinet 双通信协议，实现数据高速传输与远程监控，适配工业自动化组网需求。
5. 内置输入信号滤波功能，滤波时间 0.1ms-10ms 可调，适配高频脉冲信号采集，降低信号抖动导致的误触发概率。
6. 支持热插拔设计，无需停机即可更换模块，搭配冗余供电方案，提升系统连续运行能力。
7. 模块自带故障诊断功能，可实时监测通道短路、开路及过载状态，并通过指示灯与报文反馈，便于快速故障定位。
8. 工作温度范围 - 25℃~+70℃，相对湿度 10%~95% 无凝露，防护等级 IP30，适配恶劣工业现场环境。
9. 采用导轨式安装结构，安装间距仅需 25mm，可与信号调理模块紧密排布，节省控制柜安装空间。
10. 支持通道分组控制，可将 16 路输出分为 4 组独立控制，适配不同设备的时序联动需求，提升控制灵活性。
11. 输入电压兼容 12-30VDC，输出可适配 AC24V-240V/DC12V-60V 负载，适配多种工业设备电源规格。
12. 内置浪涌保护电路，可抵御 ±4kV 瞬态浪涌冲击，适配户外及高压设备附近的安装场景。
13. 支持与模拟量扩展模块级联，扩展模拟量输入通道，适配压力、温度等模拟信号采集。
14. 模块状态可通过 LED 指示灯实时显示，包括电源、通信、通道运行及故障状态，便于现场人员直观掌握设备情况。
15. 符合 CE、UL 安全认证标准，全生命周期免维护设计，配合自诊断功能，大幅降低设备运维成本。

0190-22543输入输出模块 英文资料：

0190-22543 Input/Output Module Product Features

Integrated 16 digital inputs and 16 relay outputs, supporting dry/wet contact input and AC220V/DC24V load drive, meeting the centralized control requirements of multiple devices.

The input channel adopts optoelectronic isolation technology, with an isolation voltage of ≥ 2500VAC, which can effectively resist on-site electromagnetic interference and ensure signal acquisition accuracy.

The rated current of the output relay contact is 10A, and it supports two control modes: pulse/level. It can directly drive high-power actuators such as contactors and solenoid valves.

Compatible with Modbus RTU and Profinet dual communication protocols, achieving high-speed data transmission and remote monitoring, and adapting to industrial automation networking requirements.

Built in input signal filtering function, adjustable filtering time from 0.1ms to 10ms, suitable for high-frequency pulse signal acquisition, reducing the probability of false triggering caused by signal jitter.

Supports hot swappable design, allowing for module replacement without the need for downtime. Equipped with a redundant power supply solution, it enhances the system's continuous operation capability.

The module comes with fault diagnosis function, which can monitor channel short circuit, open circuit and overload status in real time, and provide feedback through indicator lights and messages for quick fault location.

Working temperature range -25 ℃~+70 ℃, relative humidity 10%~95%, no condensation, protection level IP30, suitable for harsh industrial site environments.

Adopting a guide rail installation structure, the installation spacing is only 25mm, which can be tightly arranged with the signal conditioning module, saving installation space for the control cabinet.

Support channel grouping control, which can divide 16 outputs into 4 independent control groups to adapt to the timing linkage requirements of different devices and improve control flexibility.

The input voltage is compatible with 12-30VDC, and the output can adapt to AC24V-240V/DC12V-60V loads, suitable for various industrial equipment power specifications.

Built in surge protection circuit, capable of withstanding ± 4kV transient surge impact, suitable for outdoor and installation scenarios near high-voltage equipment.

Support cascading with analog expansion modules, expand analog input channels, and adapt to analog signal acquisition such as pressure and temperature.

The module status can be displayed in real-time through LED indicator lights, including power, communication, channel operation, and fault status, making it easy for on-site personnel to intuitively grasp the equipment situation.

Compliant with CE and UL safety certification standards, with a full lifecycle maintenance free design and self diagnostic function, significantly reducing equipment operation and maintenance costs.

Summary: The 0190-22543 input/output module has the core advantages of high isolation, strong driving, and multi protocol compatibility. It has anti-interference, flexibility, and reliability, outstanding signal acquisition and equipment control capabilities, and can effectively improve the integration and operational stability of industrial automation systems.
