SANYO DENKI P60B18550RBV0千瓦制动器
1.产 品 资 料 介 绍：
- SANYO DENKI P60B18550RBV0 是带电磁制动器的中功率交流电伺服电机，额定功率 5.5kW、额定转速 1500rpm，兼具强劲动力与制动锁止功能，适合重型输送线、升降式加工设备等需紧急停驻的场景。
- 4-8 台该电机可通过总线协同控制，驱动重型生产线的传动系统，比如汽车底盘装配线的升降平台，制动响应时间≤0.1 秒，能在断电或紧急停机时快速锁止电机轴，避免设备滑行风险。
- 适配三相 380V 工业标准电源，制动器供电为 DC24V，可直接接入工厂高压供电回路与低压控制回路，无需额外配置电源转换模块，降低电路部署复杂度。
- 采用大扭矩电磁制动器设计，制动扭矩达 25N・m，电机停机后能稳定锁止负载，即使在倾斜 30° 的输送轨道上，也可防止物料滑落，提升设备运行安全性。
- 能与同品牌 60 系列伺服驱动器（如 60BB075FXW14）快速匹配，通过驱动器参数设置可调节制动延时与释放时序，适配不同负载的启停需求，缩短调试周期。
- 内置 2500 线高精度增量式编码器，配合制动器的精准锁止，可实现 “驱动 - 定位 - 制动” 一体化控制，位置重复精度达 ±0.005mm，满足重型精密加工的定位需求。
- 制动器采用常闭设计，断电后自动抱闸锁止，通电后 0.05 秒内释放，适配间歇式生产场景，比如数控机床换刀机构，可在换刀过程中稳定锁止电机轴，避免刀架偏移。
- 机身采用 IP54 防护等级，制动器外壳额外做密封处理，能抵御车间粉尘、切削液飞溅，即使在机械加工车间的潮湿油污环境中，也可保障制动组件的使用寿命。
- 定子绕组采用 H 级耐高温漆包线，长期运行时绕组温度稳定在 90℃以下，制动器线圈散热结构优化，连续制动 10 次后温度不超过 60℃，适配高频启停的重型工况。
- 整体在高功率输出、安全制动、精密定位上表现突出，无论是单台用于重型升降设备，还是多台批量部署于重型生产线，都能为工业自动化提供可靠的动力与安全保障。
SANYO DENKI P60B18550RBV0千瓦制动器 英文资料：
SANYO DENKI P60B18550RBV0 is a medium power AC servo motor with an electromagnetic brake. It has a rated power of 5.5kW and a rated speed of 1500rpm, and combines strong power and braking locking function. It is suitable for emergency parking scenarios such as heavy-duty conveyor lines and lifting processing equipment.
4-8 of these motors can be controlled through bus coordination to drive the transmission system of heavy-duty production lines, such as the lifting platform of automotive chassis assembly lines. The braking response time is ≤ 0.1 seconds, and the motor shaft can be quickly locked in case of power failure or emergency stop, avoiding the risk of equipment sliding.
Compatible with three-phase 380V industrial standard power supply, the brake power supply is DC24V, which can be directly connected to the factory's high-voltage power supply circuit and low-voltage control circuit without the need for additional power conversion modules, reducing the complexity of circuit deployment.
Adopting a high torque electromagnetic brake design, the braking torque reaches 25N · m, and the motor can stably lock the load after stopping. Even on a tilted 30 ° conveyor track, it can prevent material from slipping and improve the safety of equipment operation.
It can quickly match with 60 series servo drives of the same brand (such as 60BB075FXW14), adjust the braking delay and release timing through driver parameter settings, adapt to the start stop requirements of different loads, and shorten the debugging cycle.
Built in 2500 line high-precision incremental encoder, coupled with precise locking of the brake, can achieve integrated control of "drive positioning brake", with a position repetition accuracy of ± 0.005mm, meeting the positioning requirements of heavy-duty precision machining.
The brake adopts a normally closed design, which automatically locks the brake after power failure and releases within 0.05 seconds after power on. It is suitable for intermittent production scenarios, such as the tool changing mechanism of CNC machine tools, which can stably lock the motor shaft during the tool changing process and avoid tool holder deviation.
The body adopts IP54 protection level, and the brake housing is additionally sealed to resist workshop dust and cutting fluid splashes. Even in the humid and oily environment of the machining workshop, the service life of the brake components can be guaranteed.
The stator winding adopts H-grade high-temperature resistant enameled wire, and the winding temperature remains stable below 90 ℃ during long-term operation. The heat dissipation structure of the brake coil is optimized, and the temperature does not exceed 60 ℃ after 10 consecutive braking cycles, suitable for high-frequency start stop heavy-duty working conditions.
Overall, it performs outstandingly in high power output, safe braking, and precise positioning. Whether used alone for heavy-duty lifting equipment or deployed in batches on heavy-duty production lines, it can provide reliable power and safety guarantees for industrial automation.
SANYO DENKI P60B18550RBV0千瓦制动器 产品展示
产品视频
