1.产 品 资 料 介 绍：
P0922VW FBM218 冗余输出模块 产品特点
- 8 通道隔离输出：8 路独立隔离输出通道，每路可输出 4–20mA 模拟信号，或叠加 HART 数字信号的 4–20mA 信号，支持标准仪表与 HART 智能设备混合接入。
- 模块级冗余架构：成对配置为主 / 从（Master/Tracker）模式，共用现场端子；主模块故障时，从模块自动无扰接管输出，故障模块输出强制归零，保障回路连续。
- HART 双向通信：兼容 HART 5/6/7 版协议，每秒可与现场设备交互 2 条数字消息，支持通用 / 常用 / 设备专用命令，可远程组态、读取诊断与参数。
- 高等级电气隔离：通道间、通道对地、通道对模块逻辑采用光电 + 变压器双重隔离，可承受 600VAC 耐压测试，抗干扰与安全性强。
- 冗余现场总线：通过 2Mbps 冗余 HDLC 现场总线与 FCM/FCP 通信，通信链路双备份，提升系统整体可靠性。
- 完善故障安全机制：支持通道级故障安全配置（保持 /fallback），可设定故障时输出 0mA 等安全值，适配不同工艺安全需求。
- 高精度与稳定性：输出精度高、稳定性好，满足过程控制对模拟输出的严格要求。
- 热插拔与易维护：支持在线热插拔，更换模块无需系统停机，降低维护对生产的影响。
- 工业级环境适应：工作温度 - 20℃~+70℃，抗振动、抗冲击，适配化工、电力、冶金等严苛工况。
- 原生兼容 Foxboro 系统：无缝集成 I/A Series 与 Evo DCS，组态便捷，数据传输稳定可靠。
P0922VW FBM218冗余输出模块 英文资料：
P0922VW FBM218 Redundant Output Module Product Features
8-channel isolated output: 8 independent isolated output channels, each capable of outputting 4-20mA analog signals or 4-20mA signals combined with HART digital signals, supporting mixed access of standard instruments and HART smart devices.
Module level redundant architecture: paired configuration in Master/Tracker mode, sharing on-site terminals; When the main module fails, the slave module automatically takes over the output without disturbance, and the output of the faulty module is forcibly reset to zero to ensure the continuity of the circuit.
HART bidirectional communication: compatible with HART 5/6/7 protocols, capable of exchanging 2 digital messages with field devices per second, supporting general/common/device specific commands, and capable of remote configuration, reading diagnostics and parameters.
High level electrical isolation: Channel to channel, channel to ground, and channel to module logic adopt dual isolation of optoelectronics and transformers, which can withstand 600VAC withstand voltage testing, with strong anti-interference and safety.
Redundant fieldbus: communicates with FCM/FCP through a 2Mbps redundant HDLC fieldbus, with dual backup communication links to enhance overall system reliability.
Improve the fault safety mechanism: support channel level fault safety configuration (maintain/rollback), can set safety values such as 0mA in case of fault, and adapt to different process safety requirements.
High precision and stability: High output precision and good stability meet the strict requirements of process control for analog output.
Hot swappable and easy to maintain: supports online hot swappable, module replacement does not require system shutdown, reducing the impact of maintenance on production.
Industrial grade environment adaptation: working temperature -20 ℃~+70 ℃, resistant to vibration and impact, suitable for harsh working conditions such as chemical, power, metallurgy, etc.
Native compatibility with Foxboro system: seamless integration of I/A Series and Evo DCS, convenient configuration, stable and reliable data transmission.
P0922VW FBM218 is designed for high availability process control scenarios with core advantages of redundancy, reliability, isolation safety, and HART compatibility. It is a key module for analog output and intelligent device communication in industrial automation systems.
P0922VW FBM218冗余输出模块 产品展示
