TOYOTA TP-8901-1 电路板
1.产 品 资 料 介 绍：
- 型号：TP-8901-1（FHOUT-F）
- 类型：继电器输出电路板，专门用于实现继电器输出控制功能。
- 输出通道：具备 36 路继电器输出，可同时对多个外部执行器进行控制，满足复杂工业场景的控制需求。
- 接口配置：配备 15 个 12 针母连接器，方便与其他设备进行连接；同时设有 2 个 CDJR-1 接口，进一步拓展了连接的灵活性。
- 安装方式：支持模块化机架安装，可稳定地安装在机架上；也可采用插槽安装，便于快速安装和更换，适应不同的设备安装环境。
- 适用环境：针对工业现场设计，具备出色的抗震动能力，能在设备运行产生振动的环境下保持稳定工作；同时耐温差能力较强，可适应工业现场较大的温度变化。
- 配套使用：与 TP-8900-0 输入板配合使用，能够构成完整的 I/O 系统，实现信号的输入与输出，确保系统的正常运行。
- CNC 数控机床：在 CNC 数控机床中，用于控制机床的外部执行装置，如液压夹具的松紧控制、冷却系统的启停、照明的开关以及信号指示灯的状态显示等，保障数控机床的正常运转。
- 自动化产线控制：作为生产线控制系统的输出模块，能够驱动电磁阀、继电器组、机械手臂等自动化部件，实现自动化产线的有序运行，提高生产效率。
- 工业控制柜：可集成在自动化控制柜中，作为集中输出控制板使用，对柜内及连接的外部设备进行集中控制，简化控制线路，提高控制柜的运行稳定性。
- 设备维护与替换：适用于维修或升级老旧的 Toyoda 控制系统，当系统中的输出板出现故障时，可作为替换件进行更换，有效延长设备的使用寿命，降低设备更换成本。
英文资料：
Introduction to TOYOTA TP-8901-1 Circuit Board
TOYOTA TP-8901-1 circuit board (model FHOUT-F TP-8901-1) is a relay output control module suitable for industrial automation equipment and plays an important role in industrial control systems. It is usually used in conjunction with the TP-8900-0 (FHIN-F) input board, and the two work together to form the signal input and output core of CNC machine tools or automation control systems. This circuit board has the ability to output multiple relays, which can accurately drive external actuators, thereby achieving precise control of industrial equipment and providing strong support for the stable operation of industrial production.
Technical parameters
Model: TP-8901-1 (FHOUT-F)
Type: Relay output circuit board, specifically designed to implement relay output control functions.
Output channel: Equipped with 36 relay outputs, it can simultaneously control multiple external actuators to meet the control requirements of complex industrial scenarios.
Interface configuration: equipped with 15 12 pin female connectors for easy connection with other devices; At the same time, there are two CDJR-1 interfaces, further expanding the flexibility of the connection.
Installation method: Supports modular rack installation and can be stably installed on the rack; Slot installation can also be used for quick installation and replacement, adapting to different device installation environments.
Applicable environment: Designed for industrial sites, it has excellent anti vibration capabilities and can maintain stable operation in environments where equipment generates vibration during operation; At the same time, it has strong temperature tolerance and can adapt to large temperature changes in industrial sites.
Supporting use: When used in conjunction with the TP-8900-0 input board, it can form a complete I/O system, achieve signal input and output, and ensure the normal operation of the system.
Application scenarios
CNC machine tool: In CNC machine tools, it is used to control the external execution devices of the machine tool, such as the tightness control of hydraulic fixtures, the start and stop of cooling systems, the switch of lighting, and the status display of signal indicators, to ensure the normal operation of the CNC machine tool.
Automated production line control: As an output module of the production line control system, it can drive automation components such as solenoid valves, relay groups, and robotic arms to achieve orderly operation of the automated production line and improve production efficiency.
Industrial control cabinet: It can be integrated into an automation control cabinet and used as a centralized output control board to centrally control the internal and external devices connected to the cabinet, simplify the control circuit, and improve the operational stability of the control cabinet.
Equipment maintenance and replacement: suitable for repairing or upgrading old Toyota control systems. When the output board in the system fails, it can be replaced as a replacement part, effectively extending the service life of the equipment and reducing equipment replacement costs.
