SANYO DENKI PEAAI50MXXXC0I伺服驱动器
1.产 品 资 料 介 绍：
- SANYO DENKI PEAAI50MXXXC0I 是中大功率伺服驱动器，额定输出电流 50A，适配 5.5kW-7.5kW 的伺服电机，主打高负载驱动与稳定控制，适合重型数控机床主轴、冶金设备传动机构等对动力输出与运行稳定性有高要求的工业场景。
- 4-8 台该驱动器可通过 EtherCAT 工业总线实现高速协同控制，驱动生产线多轴重型执行部件，比如风电齿轮箱加工线的铣削机构，能同步各轴切削速度与进给量，确保齿轮箱齿面精度达 6 级以上，加工合格率提升至 99.3% 以上。
- 适配三相 380V-480V 工业标准电源，输入电压波动允许范围 ±15%（323V-552V），可适应重型工业车间供电电压的较大波动，无需额外配置高压稳压设备，降低复杂供电环境下的设备部署成本。
- 采用落地式 + 模块化设计，机身防护等级达 IP20，核心驱动模块与散热模块独立布局，散热风扇支持智能调速（根据温度自动切换转速），24 小时满负载运行时机身温度可控制在 70℃以下，避免高温影响驱动性能。
- 能与同品牌 P 系列大功率伺服电机（如 P60B18550RBV0）无缝兼容，支持 “电机参数自动校准” 功能，通电后可自动识别电机型号、绕组参数并加载最优控制参数，避免人工调试误差，调试时间缩短至 40 分钟以内。
- 支持位置、速度、扭矩、转矩限制四种控制模式，位置控制时脉冲响应频率达 1MHz，配合高精度电子凸轮与齿轮同步功能，可实现复杂轨迹运动控制，满足大型异形件加工时的曲线进给需求。
- 内置过流、过压、过载、欠压、过热、编码器故障、电机堵转七种保护功能，故障发生时会立即切断输出并触发声光报警，同时将故障数据存储至本地内存（可保存近 30 条故障记录），工作人员通过配套诊断软件可回溯故障前 1 分钟运行曲线，快速定位问题根源。
SANYO DENKI PEAAI50MXXXC0I伺服驱动器 英文资料：
SANYO DENKI PEAAI50MXXXC0I is a medium to high power servo drive with a rated output current of 50A. It is compatible with servo motors ranging from 5.5kW to 7.5kW and focuses on high load drive and stable control. It is suitable for industrial scenarios such as heavy-duty CNC machine tool spindles and metallurgical equipment transmission mechanisms that require high power output and operational stability.
4-8 units of this driver can achieve high-speed collaborative control through EtherCAT industrial bus, driving multi axis heavy-duty execution components on the production line, such as the milling mechanism of a wind turbine gearbox machining line. It can synchronize the cutting speed and feed rate of each axis, ensuring that the precision of the gearbox tooth surface reaches level 6 or above, and the machining pass rate is increased to over 99.3%.
Suitable for three-phase 380V-480V industrial standard power supply, with an allowable range of input voltage fluctuation of ± 15% (323V-552V), it can adapt to large fluctuations in power supply voltage in heavy-duty industrial workshops, without the need for additional high-voltage stabilizing equipment, reducing equipment deployment costs in complex power supply environments.
Adopting a floor standing and modular design, the body protection level reaches IP20. The core driver module and heat dissipation module are independently arranged, and the heat dissipation fan supports intelligent speed regulation (automatically switches speed according to temperature). When running at full load for 24 hours, the body temperature can be controlled below 70 ℃ to avoid high temperature affecting the driving performance.
It is seamlessly compatible with P series high-power servo motors of the same brand (such as P60B18550RBV0), supports the "motor parameter automatic calibration" function, and can automatically identify the motor model, winding parameters, and load the optimal control parameters after power on, avoiding manual debugging errors and shortening the debugging time to less than 40 minutes.
Supports four control modes: position, speed, torque, and torque limit. The pulse response frequency during position control reaches 1MHz. Combined with high-precision electronic cam and gear synchronization function, it can achieve complex trajectory motion control and meet the curve feed requirements during the processing of large shaped parts.
Built in seven protection functions including overcurrent, overvoltage, overload, undervoltage, overheating, encoder failure, and motor stalling. When a fault occurs, the output will be immediately cut off and an audible and visual alarm will be triggered. At the same time, the fault data will be stored in the local memory (which can save nearly 30 fault records). The staff can trace the operating curve of the previous minute through the supporting diagnostic software to quickly locate the root cause of the problem.
SANYO DENKI PEAAI50MXXXC0I伺服驱动器 产品展示
