SANYO DENKI 61BA050FXWN1 控制器模块
1.产 品 资 料 介 绍：
- 中功率精准控制性能：作为 61BA 系列核心控制器模块，61BA050FXWN1 采用高精度数字控制芯片与优化调控算法，适配 500W 级伺服电机驱动需求，能精准转换上位系统指令为电机控制信号，在小型数控机床进给轴、精密输送设备等场景中，实现转矩与转速的精细化调节，控制误差可低至 ±0.1%，保障设备运行精度。
- 高动态响应处理能力：内置高速信号处理单元，指令响应延迟控制在毫秒级，能快速捕捉负载波动与速度指令变化，在高速分拣、精密装配等需频繁启停的场景中，可实现无超调的动态跟随，避免因响应滞后导致的定位偏差，提升设备生产效率。
- 多系统兼容适配特性：采用标准化接口设计，不仅可无缝匹配同品牌 61 系列伺服电机，还兼容主流工业控制系统的信号协议，在老旧设备升级或系统改造时，无需大规模调整硬件架构，仅通过参数调试即可完成适配，大幅降低兼容成本与停机时间。
- 灵活负载适配能力：支持 S3 峰值负载与 S1 连续负载两种模式切换，可根据机械轴的实际工况（如暂时加速的短时重载或持续运行的稳定负载）自动调整输出参数，适配激光加工、装卸设备等多负载类型场景，提升系统运行灵活性。
- 工业级抗干扰设计：内置多级信号滤波模块与电磁屏蔽结构，能有效过滤工业现场的电磁干扰信号，即使在多设备集中运行的复杂电磁环境中，也能维持控制信号的稳定性，减少因干扰导致的运行波动，降低人工调试频次。
- 紧凑型安装与环境适配：采用 198×247mm 等小型化尺寸设计（参考同系列尺寸规格），占用控制柜空间小，适配设备密集布局场景；外壳防护等级达 IP40 及以上，可抵御粉尘与轻微湿气侵袭，在 0-50℃温度区间稳定工作，契合机床车间、电子厂房等常规工业环境需求。
- 全维度安全防护机制：集成过流、过压、过热及信号异常保护功能，当检测到电流过载、电压波动或自身温度超标时，立即触发保护机制切断输出并发送报警信号，防止模块及关联设备损坏，降低维修成本与生产风险。
- 便捷运维与状态监控：支持通过外接调试端口或上位系统实现参数配置与状态读取，可实时反馈运行电流、温度、负载率等关键数据，配合故障代码自动记录功能，便于操作人员快速排查异常，缩短设备运维停机时间。
SANYO DENKI 61BA050FXWN1 控制器模块 英文资料：
Medium power precision control performance: As the core controller module of the 61BA series, the 61BA050FXWN1 adopts high-precision digital control chips and optimized control algorithms to adapt to the driving requirements of 500W level servo motors. It can accurately convert upper system instructions into motor control signals, and achieve precise adjustment of torque and speed in small CNC machine feed axes, precision conveying equipment and other scenarios. The control error can be as low as ± 0.1%, ensuring the accuracy of equipment operation.
High dynamic response processing capability: Equipped with a built-in high-speed signal processing unit, the instruction response delay is controlled at the millisecond level, which can quickly capture load fluctuations and speed instruction changes. In scenarios such as high-speed sorting and precision assembly that require frequent start stop, it can achieve dynamic tracking without overshoot, avoid positioning deviation caused by response lag, and improve equipment production efficiency.
Multi system compatibility and adaptation features: adopting standardized interface design, not only can seamlessly match the 61 series servo motors of the same brand, but also compatible with the signal protocols of mainstream industrial control systems. When upgrading old equipment or renovating systems, there is no need to adjust the hardware architecture on a large scale, and adaptation can be completed through parameter debugging, greatly reducing compatibility costs and downtime.
Flexible load adaptation capability: Supports switching between S3 peak load and S1 continuous load modes, and can automatically adjust output parameters according to the actual working conditions of the mechanical shaft (such as short-term heavy load for temporary acceleration or stable load for continuous operation), adapting to multiple load types such as laser processing and loading and unloading equipment, and improving system operation flexibility.
Industrial grade anti-interference design: Equipped with multi-level signal filtering modules and electromagnetic shielding structures, it can effectively filter electromagnetic interference signals in industrial sites. Even in complex electromagnetic environments where multiple devices are running centrally, it can maintain the stability of control signals, reduce operational fluctuations caused by interference, and lower the frequency of manual debugging.
Compact installation and environmental adaptation: Designed with miniaturized dimensions such as 198 × 247mm (referring to the same series size specifications), it occupies less control cabinet space and is suitable for equipment intensive layout scenarios; The shell protection level reaches IP40 or above, which can resist the invasion of dust and slight moisture, and work stably in the temperature range of 0-50 ℃, meeting the requirements of conventional industrial environments such as machine tool workshops and electronic factories.
Full dimensional security protection mechanism: integrates overcurrent, overvoltage, overheating, and signal abnormality protection functions. When current overload, voltage fluctuation, or self temperature exceeding the standard is detected, the protection mechanism is immediately triggered to cut off the output and send an alarm signal to prevent module and related equipment damage, reduce maintenance costs and production risks.
Convenient operation and status monitoring: Supports parameter configuration and status reading through external debugging ports or upper level systems, providing real-time feedback on key data such as operating current, temperature, and load rate. Combined with automatic fault code recording function, it facilitates operators to quickly troubleshoot abnormalities and shorten equipment operation and maintenance downtime.
SANYO DENKI 61BA050FXWN1 控制器模块 产品展示
产品视频
