SANYO DENKI P50B05020DXS00主轴电机
1.产 品 资 料 介 绍：
- 中小功率精准驱动：作为 P5 系列经典主轴型号，P50B05020DXS00 额定功率适配 200W 级应用场景，采用优化电磁设计实现高效能量转换，在小型数控机床、精密加工设备中可提供稳定动力输出，兼顾能效与驱动精度。
- 高分辨率定位控制：搭载高精度光学编码器（参考系列 2000 线及以上配置），配合全闭环反馈系统，能实现微米级位置定位，在 PCB 铣削、小型模具加工等场景中，有效提升工件加工表面质量与尺寸一致性。
- 宽速域平稳运行：转速调节范围覆盖低速恒转矩到高速轻载区间，最高转速可达 3000rpm 以上，通过优化转子结构降低齿槽转矩，低速运行时转速波动量显著降低，适配精密研磨、精细雕刻等多速度需求场景。
- 全系列驱动器兼容：可无缝匹配同品牌 PZ、PU、PV 等系列伺服驱动器，无需额外调整参数即可实现联动控制，在老旧日系小型设备升级维护中，能直接替换原有 P5 系列电机，大幅降低适配调试成本。
- 强化耐环境设计：采用高刚性轴承与优化动平衡工艺，运行噪音低于 60dB，振动幅度控制在 0.1mm 以内；机身具备 IP54 及以上防护等级，可抵御加工车间粉尘与轻微油污，适配 0~40℃常规工业环境。
- 低耗易维护结构：通过低损耗电磁材料应用，电机能量损失较传统型号降低 10% 以上；采用一体化飞线设计，简化接线流程，配合标准化部件选型，后期更换维护便捷，降低设备停机时间。
- 多层级安全防护：内置过载、过流、过热三重保护模块，当负载超过额定值 150% 时自动切断输出，同时具备欠压、过压保护功能，防止电机及关联设备因异常工况损坏，提升生产安全性。
- 小型设备专项适配：凭借紧凑机身设计（参考系列 54×54mm 法兰尺寸）与精准控制性能，广泛应用于小型数控机床、精密检测仪器、纺织机械主轴等领域，既是新设备配套优选，也是小型老旧设备维护的标杆替换件。
SANYO DENKI P50B05020DXS00主轴电机 英文资料：
Small and Medium Power Precision Drive: As a classic spindle model of the P5 series, P50B05020DXS00 has a rated power suitable for 200W level application scenarios. It adopts optimized electromagnetic design to achieve efficient energy conversion and can provide stable power output in small CNC machine tools and precision machining equipment, balancing energy efficiency and drive accuracy.
High resolution positioning control: Equipped with a high-precision optical encoder (reference series 2000 line and above configuration), combined with a fully closed-loop feedback system, it can achieve micrometer level position positioning, effectively improving the surface quality and size consistency of workpiece processing in PCB milling, small mold processing and other scenarios.
Smooth operation in a wide speed range: The speed adjustment range covers the low-speed constant torque to high-speed light load range, with a maximum speed of over 3000rpm. By optimizing the rotor structure to reduce cogging torque, the speed fluctuation during low-speed operation is significantly reduced, making it suitable for multi speed demand scenarios such as precision grinding and fine carving.
Full range drive compatibility: It can seamlessly match servo drives of the same brand such as PZ, PU, PV, etc., without the need for additional parameter adjustment to achieve linkage control. In the upgrade and maintenance of old Japanese small equipment, it can directly ｒｅｐｌａｃｅ the original P5 series motor, greatly reducing the cost of adaptation and debugging.
Enhanced environmental resistance design: using high rigidity bearings and optimized dynamic balancing technology, the operating noise is below 60dB, and the vibration amplitude is controlled within 0.1mm; The body has a protection level of IP54 or above, which can resist dust and slight oil stains in the processing workshop, and is suitable for conventional industrial environments ranging from 0 to 40 ℃.
Low consumption and easy maintenance structure: By using low loss electromagnetic materials, the energy loss of the motor is reduced by more than 10% compared to traditional models; Adopting an integrated flying wire design, simplifying the wiring process, and coordinating with standardized component selection, it is easy to ｒｅｐｌａｃｅ and maintain in the later stage, reducing equipment downtime.
Multi level safety protection: Equipped with triple protection modules for overload, overcurrent, and overheating, it automatically cuts off the output when the load exceeds 150% of the rated value. At the same time, it has undervoltage and overvoltage protection functions to prevent motor and related equipment from being damaged due to abnormal working conditions and improve production safety.
Specialized adaptation for small equipment: With a compact body design (reference series 54 × 54mm flange size) and precise control performance, it is widely used in small CNC machine tools, precision testing instruments, textile machinery spindles and other fields. It is not only the preferred choice for new equipment matching, but also the benchmark replacement for maintenance of small and old equipment.
SANYO DENKI P50B05020DXS00主轴电机 产品展示
产品视频
