SANYO DENKI Q1AA13500DXP00 主轴电机
1.产 品 资 料 介 绍：
- 高功率密度动力输出：作为 Q 系列主轴电机代表型号，Q1AA13500DXP00 采用优化电磁绕组与磁钢布局设计，在紧凑机身内实现高效功率转换，额定功率适配中大功率应用场景，能为数控机床切削、精密加工设备主轴提供持续稳定的动力，兼顾动力强度与运行效率。
- 微米级主轴定位精度：搭载高分辨率绝对值编码器（参考系列高精度反馈配置），配合全闭环反馈控制系统，定位误差可控制在微米级，在模具精铣、半导体器件加工等场景中，能精准控制主轴旋转位置与进给配合，大幅提升工件加工精度与表面光洁度。
- 宽速域平稳运行特性：转速调节范围覆盖低速恒转矩到高速轻载区间，最高转速可达数千转 / 分钟，通过优化转子动平衡与齿槽转矩抑制技术，低速运行时转速波动量显著降低，高速运转时振动幅度小，适配精密研磨、高速切削等多速度段切换的加工需求。
- 强控制器兼容适配性：可无缝匹配同品牌 Q 系列、PY 系列伺服控制器，无需额外调整接口参数即可实现联动控制，在老旧设备升级或主轴电机替换场景中，能直接适配原有控制系统，减少硬件改造与调试成本，缩短设备停机时间。
- 低耗高效散热设计：采用低损耗电磁材料与高效散热风道结构，电机运行能耗较传统型号降低 10% 以上，同时能快速导出运行过程中产生的热量，避免因高温导致性能衰减，保障电机在长时间连续加工工况下（如批量零件生产）的稳定运行。
- 耐工业环境结构防护：机身采用高刚性外壳与密封设计，防护等级可达 IP54 及以上，能抵御加工车间的粉尘、冷却液飞溅等环境干扰；同时优化轴承选型，提升抗磨损与抗冲击能力，适配机床车间、汽车零部件加工等复杂工业场景。
SANYO DENKI Q1AA13500DXP00 主轴电机 英文资料：
High power density power output: As a representative model of Q-series spindle motors, Q1AA13500DXP00 adopts optimized electromagnetic winding and magnetic steel layout design to achieve efficient power conversion in a compact body. The rated power is suitable for medium and high power application scenarios, and can provide continuous and stable power for CNC machine cutting and precision machining equipment spindles, balancing power intensity and operating efficiency.
Micron level spindle positioning accuracy: Equipped with a high-resolution absolute value encoder (reference series high-precision feedback configuration), combined with a fully closed-loop feedback control system, the positioning error can be controlled at the micrometer level. In scenarios such as mold precision milling and semiconductor device processing, the spindle rotation position and feed coordination can be accurately controlled, greatly improving the machining accuracy and surface smoothness of workpieces.
Wide speed range smooth operation characteristics: The speed adjustment range covers the low-speed constant torque to high-speed light load range, and the highest speed can reach thousands of revolutions per minute. By optimizing the rotor dynamic balance and cogging torque suppression technology, the speed fluctuation is significantly reduced during low-speed operation, and the vibration amplitude is small during high-speed operation, which is suitable for the machining needs of multi speed range switching such as precision grinding and high-speed cutting.
Strong controller compatibility and adaptability: It can seamlessly match Q series and PY series servo controllers of the same brand, without the need to adjust interface parameters to achieve linkage control. In the scenario of upgrading old equipment or replacing spindle motors, it can directly adapt to the original control system, reduce hardware modification and debugging costs, and shorten equipment downtime.
Low consumption and high-efficiency heat dissipation design: Using low loss electromagnetic materials and high-efficiency heat dissipation duct structure, the energy consumption of the motor during operation is reduced by more than 10% compared to traditional models. At the same time, the heat generated during operation can be quickly exported to avoid performance degradation caused by high temperature, ensuring the stable operation of the motor under long-term continuous processing conditions (such as batch part production).
Industrial environment resistant structural protection: The body adopts a high rigidity shell and sealed design, with a protection level of IP54 or above, which can resist environmental interference such as dust and coolant splashing in the processing workshop; Simultaneously optimize the selection of bearings, enhance wear and impact resistance, and adapt to complex industrial scenarios such as machine tool workshops and automotive parts processing.
SANYO DENKI Q1AA13500DXP00 主轴电机 产品展示
产品视频
